Sony CDX-M50IP - Sub (AUX) Panel Assy; CD Mechanism Block

11
CDX-M50IP/MR50IP
3-2. CD MECHANISM BLOCK
Note: Follow the disassembly procedure in the numerical order given.
3-1. SUB (AUX) PANEL ASSY
2 two claw
s
3 two claws
5 sub (AUX) panel assy
1 two screws
(+PTT 2.6
× 6)
4 flexible flat cable (17 core)
(CN802)
4 CN350
3
1 screw
(+PTT 2.6
× 6)
2 screw
(+PTT 2.6
× 6)
5 two screws
(+PTT 2.6
× 4)
6 bracket (CD)
7 CD mechanism block
