Sony CDX-M50IP - Electrical Parts List; iPod Board Parts List; Key Board Parts List

40
CDX-M50IP/MR50IP
SECTION 7
ELECTRICAL PARTS LIST
IPOD BOARD
***********
< CAPACITOR >
C250 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C251 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C252 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C253 1-164-730-11 CERAMIC CHIP 0.0012uF 10% 50V
C254 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C255 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C256 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< DIODE >
D250 8-719-060-48 DIODE RB751V-40TE-17
< IC >
IC250 6-807-885-01 IC ATMEGA32L-8AU-S6
< JUMPER RESISTOR >
JC201 1-216-296-11 SHORT CHIP 0
JC202 1-216-296-11 SHORT CHIP 0
JC203 1-216-864-11 SHORT CHIP 0
JC205 1-216-296-11 SHORT CHIP 0
< RESISTOR >
R241 1-216-845-11 METAL CHIP 100K 5% 1/10W
R250 1-216-841-11 METAL CHIP 47K 5% 1/10W
R251 1-216-833-11 METAL CHIP 10K 5% 1/10W
R252 1-216-864-11 SHORT CHIP 0
R253 1-216-833-11 METAL CHIP 10K 5% 1/10W
R254 1-216-864-11 SHORT CHIP 0
R255 1-216-833-11 METAL CHIP 10K 5% 1/10W
R256 1-216-845-11 METAL CHIP 100K 5% 1/10W
R257 1-216-845-11 METAL CHIP 100K 5% 1/10W
R259 1-216-845-11 METAL CHIP 100K 5% 1/10W
R260 1-216-845-11 METAL CHIP 100K 5% 1/10W
R261 1-216-845-11 METAL CHIP 100K 5% 1/10W
R262 1-216-845-11 METAL CHIP 100K 5% 1/10W
R263 1-216-845-11 METAL CHIP 100K 5% 1/10W
R264 1-216-845-11 METAL CHIP 100K 5% 1/10W
R265 1-216-845-11 METAL CHIP 100K 5% 1/10W
R266 1-216-845-11 METAL CHIP 100K 5% 1/10W
R267 1-216-845-11 METAL CHIP 100K 5% 1/10W
R268 1-216-845-11 METAL CHIP 100K 5% 1/10W
R270 1-216-821-11 METAL CHIP 1K 5% 1/10W
R288 1-216-845-11 METAL CHIP 100K 5% 1/10W
< VIBRATOR >
X250 1-795-825-21 VIBRATOR, CRYSTAL (7.3728MHz)
*************************************************************
KEY BOARD
**********
1-780-563-11 CONDUCTIVE BOARD, CONNECTION
< CAPACITOR >
C971 1-135-834-11 CERAMIC CHIP 2.2uF 6.3V
C980 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C981 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C982 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C983 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C984 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
< CONNECTOR >
CN901 1-819-783-11 PLUG, CONNECTOR 16P
< DIODE >
D903 6-501-738-01 DIODE MAZ8062GMLS0
D904 6-501-738-01 DIODE MAZ8062GMLS0
D905 6-501-738-01 DIODE MAZ8062GMLS0
D906 6-501-738-01 DIODE MAZ8062GMLS0
D907 6-501-738-01 DIODE MAZ8062GMLS0
D908 6-501-738-01 DIODE MAZ8062GMLS0
D909 6-501-738-01 DIODE MAZ8062GMLS0
D911 6-501-782-01 DIODE MAZ8180GMLS0
D981 6-501-738-01 DIODE MAZ8062GMLS0
D982 6-501-782-01 DIODE MAZ8180GMLS0
D984 6-501-817-01 DIODE MA2J1110GLS0
< JUMPER RESISTOR >
FB880 1-216-864-11 SHORT CHIP 0
FB881 1-216-864-11 SHORT CHIP 0
FB882 1-216-864-11 SHORT CHIP 0
< IC >
IC901 6-707-064-01 IC LC75876WH-US-E
IC971 6-600-629-01 IC RS-470 (IR)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
KEY
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
IPOD
