Sony CDX-M50IP - Electrical Parts List (Key Components); Key Components List

41
CDX-M50IP/MR50IP
< JACK >
J901 1-820-833-11 JACK, SMALL TYPE (VERTICAL) (AUX)
< LIQUID CRYSTAL DISPLAY >
LCD901 1-802-536-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED902 8-719-053-09 LED SML-310VTT86 (SOURCE)
LED903 8-719-053-09 LED SML-310VTT86 (SEEK+/M >)
LED904 8-719-053-09 LED SML-310VTT86 (MODE)
LED905 8-719-053-09 LED SML-310VTT86 (OFF)
LED906 8-719-053-09 LED SML-310VTT86 (ALBM –)
LED907 8-719-053-09 LED SML-310VTT86 (SEEK–/. m)
LED908 8-719-053-09 LED SML-310VTT86 (ALBM +)
LED909 8-719-053-09 LED SML-310VTT86 (DSPL/SCRL)
LED910 8-719-053-09 LED SML-310VTT86 (6/PAUSE)
LED911 8-719-053-09 LED SML-310VTT86 (5)
LED912 8-719-053-09 LED SML-310VTT86 (4/SHUF)
LED913 8-719-053-09 LED SML-310VTT86 (3/REP)
LED914 8-719-053-09 LED SML-310VTT86 (2)
LED915 8-719-053-09 LED SML-310VTT86 (1)
LED916 8-719-053-09 LED SML-310VTT86 (BTM/CAT) (M50IP)
LED916 8-719-053-09 LED SML-310VTT86 (AF/TA/PTY) (MR50IP)
LED930 6-501-339-01 LED NESW505CT-AST (LCD BACK LIGHT-L)
LED931 6-501-339-01 LED NESW505CT-AST (LCD BACK LIGHT-R)
LED943 8-719-053-09 LED SML-310VTT86
(VOLUME ILLUMINATION)
LED946 6-501-547-01 LED CL-197HB1E-D-T
(VOLUME ILLUMINATION)
LED947 8-719-053-09 LED SML-310VTT86
(VOLUME ILLUMINATION)
LED948 8-719-053-09 LED SML-310VTT86
(VOLUME ILLUMINATION)
LED949 6-501-547-01 LED CL-197HB1E-D-T
(VOLUME ILLUMINATION)
LED950 8-719-053-09 LED SML-310VTT86
(VOLUME ILLUMINATION)
LED951 6-501-547-01 LED CL-197HB1E-D-T
(VOLUME ILLUMINATION)
LED952 6-501-547-01 LED CL-197HB1E-D-T (SOURCE)
LED953 6-501-547-01 LED CL-197HB1E-D-T (SEEK+/M >)
LED954 6-501-547-01 LED CL-197HB1E-D-T (MODE)
LED955 6-501-547-01 LED CL-197HB1E-D-T (OFF)
LED956 6-501-547-01 LED CL-197HB1E-D-T (ALBM –)
LED957 6-501-547-01 LED CL-197HB1E-D-T (SEEK–/. m)
LED958 6-501-547-01 LED CL-197HB1E-D-T (ALBM +)
LED959 6-501-547-01 LED CL-197HB1E-D-T (DSPL/SCRL)
LED960 6-501-547-01 LED CL-197HB1E-D-T (6/PAUSE)
LED961 6-501-547-01 LED CL-197HB1E-D-T (5)
LED962 6-501-547-01 LED CL-197HB1E-D-T (4/SHUF)
LED963 6-501-547-01 LED CL-197HB1E-D-T (3/REP)
LED964 6-501-547-01 LED CL-197HB1E-D-T (2)
LED965 6-501-547-01 LED CL-197HB1E-D-T (1)
LED966 6-501-547-01 LED CL-197HB1E-D-T (BTM/CAT) (M50IP)
LED966 6-501-547-01 LED CL-197HB1E-D-T (AF/TA/PTY) (MR50IP)
LED993 6-501-547-01 LED CL-197HB1E-D-T
(VOLUME ILLUMINATION)
< TRANSISTOR >
Q901 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q919 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q920 6-551-856-01 TRANSISTOR LTC614TKFP8T146
< RESISTOR >
R901 1-216-820-11 METAL CHIP 820 5% 1/10W
R902 1-216-821-11 METAL CHIP 1K 5% 1/10W
R903 1-216-821-11 METAL CHIP 1K 5% 1/10W
R904 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R905 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R906 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R907 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R908 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R910 1-216-820-11 METAL CHIP 820 5% 1/10W
R911 1-216-821-11 METAL CHIP 1K 5% 1/10W
R912 1-216-821-11 METAL CHIP 1K 5% 1/10W
R914 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R915 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R916 1-216-824-11 METAL CHIP 1.8K 5% 1/10W
R917 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R921 1-216-030-00 RES-CHIP 160 5% 1/10W
R922 1-216-037-00 RES-CHIP 330 5% 1/10W
R923 1-216-031-00 RES-CHIP 180 5% 1/10W
R924 1-216-037-00 RES-CHIP 330 5% 1/10W
R925 1-216-030-00 RES-CHIP 160 5% 1/10W
R926 1-216-037-00 RES-CHIP 330 5% 1/10W
R927 1-216-031-00 RES-CHIP 180 5% 1/10W
R928 1-216-037-00 RES-CHIP 330 5% 1/10W
R929 1-216-030-00 RES-CHIP 160 5% 1/10W
R930 1-216-037-00 RES-CHIP 330 5% 1/10W
R931 1-216-031-00 RES-CHIP 180 5% 1/10W
R932 1-216-037-00 RES-CHIP 330 5% 1/10W
R933 1-216-033-00 RES-CHIP 220 5% 1/10W
R934 1-216-041-00 RES-CHIP 470 5% 1/10W
R935 1-216-027-00 RES-CHIP 120 5% 1/10W
R936 1-216-037-00 RES-CHIP 330 5% 1/10W
R937 1-216-025-11 RES-CHIP 100 5% 1/10W
R938 1-216-037-00 RES-CHIP 330 5% 1/10W
R939 1-216-029-00 RES-CHIP 150 5% 1/10W
R940 1-216-045-00 RES-CHIP 680 5% 1/10W
R941 1-216-031-00 RES-CHIP 180 5% 1/10W
R942 1-216-045-00 RES-CHIP 680 5% 1/10W
R943 1-216-029-00 RES-CHIP 150 5% 1/10W
R944 1-216-037-00 RES-CHIP 330 5% 1/10W
R945 1-216-031-00 RES-CHIP 180 5% 1/10W
R946 1-216-037-00 RES-CHIP 330 5% 1/10W
R947 1-216-029-00 RES-CHIP 150 5% 1/10W
R948 1-216-045-00 RES-CHIP 680 5% 1/10W
R949 1-216-031-00 RES-CHIP 180 5% 1/10W
R950 1-216-045-00 RES-CHIP 680 5% 1/10W
R951 1-216-029-00 RES-CHIP 150 5% 1/10W
R952 1-216-037-00 RES-CHIP 330 5% 1/10W
R953 1-216-031-00 RES-CHIP 180 5% 1/10W
R954 1-216-037-00 RES-CHIP 330 5% 1/10W
R955 1-216-029-00 RES-CHIP 150 5% 1/10W
R956 1-216-045-00 RES-CHIP 680 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY
