Sony CDX-M50IP - MAIN Board; SERVO Board

12
CDX-M50IP/MR50IP
3-4. SERVO BOARD
3-3. MAIN BOARD
qf MAIN board
insulating sheet
3
2 two screws
(+PTT 2.6
× 8)
1 three ground point screws
(+PTT 2.6
× 6)
4 CN801 (8P)
5 CN803 (3P)
qa two screws
(+P 2.6
× 8)
qs screw
(+PTT 2.6
× 10)
qd heat sink
9 two screws
(+P 2.6
× 8)
0 two screws
(+PTT 2.6
× 10)
8 screw
(+PTT 2.6
× 10)
6 screw
(+PTT 2.6
× 8)
7 automobile cord (for iPod)
5 SERVO board
SERVO board
claw
claw
3 toothed lock screw
(M 1.7
× 2.5)
2 toothed lock screw
(M 1.7
× 2.5)
1 Remove the eleven solders.
GRY
YEL
BLE
ORG
RED
BLK
RED
WHT
BLK
RED
WHT
4 optical pick-up (16 core
)
(CN1)
