Sony CDX-M50IP - Electrical Parts List (Main Board - Part 2); Main Board Parts List (Part 2)

43
CDX-M50IP/MR50IP
C318 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C319 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C320 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C321 1-126-960-11 ELECT 1uF 20% 50V
C323 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C324 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C325 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C326 1-128-057-11 ELECT 330uF 20% 6.3V
C327 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C328 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C360 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C361 1-126-964-11 ELECT 10uF 20% 50V
C362 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C363 1-115-871-11 ELECT 1uF 20% 50V
C364 1-115-871-11 ELECT 1uF 20% 50V
C401 1-124-584-00 ELECT 100uF 20% 10V
C402 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C403 1-126-176-11 ELECT 220uF 20% 10V
C405 1-124-248-00 ELECT 22uF 20% 25V
C410 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C412 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C413 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C414 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C418 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C419 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C421 1-126-964-11 ELECT 10uF 20% 50V
C422 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C423 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C441 1-126-964-11 ELECT 10uF 20% 50V
C442 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C443 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C446 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C447 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C461 1-126-964-11 ELECT 10uF 20% 50V
C462 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C465 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C466 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C471 1-126-964-11 ELECT 10uF 20% 50V
C472 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C480 1-136-159-00 FILM 0.033uF 5% 50V
C481 1-136-159-00 FILM 0.033uF 5% 50V
C482 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C483 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C484 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C485 1-104-665-11 ELECT 100uF 20% 25V
C487 1-126-964-11 ELECT 10uF 20% 50V
C491 1-124-589-11 ELECT 47uF 20% 16V
C501 1-128-057-11 ELECT 330uF 20% 6.3V
C502 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C505 1-126-369-11 ELECT 220uF 20% 6.3V
C506 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C508 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C510 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C516 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C517 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C518 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C519 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C520 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C521 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C523 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C524 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C600 1-126-941-11 ELECT 470uF 20% 25V
C601 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C602 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C701 1-112-302-11 ELECT 3300uF 20% 16V
C702 1-126-160-11 ELECT 1uF 20% 50V
C703 1-126-163-11 ELECT 4.7uF 20% 50V
C704 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C705 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C802 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C803 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C804 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C805 1-126-960-11 ELECT 1uF 20% 50V
C806 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C807 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C808 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C809 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C810 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C811 1-126-964-11 ELECT 10uF 20% 50V
C812 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C813 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C815 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C816 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C817 1-124-248-00 ELECT 22uF 20% 25V
C824 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C825 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C901 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C902 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C998 1-216-864-11 SHORT CHIP 0
< CONNECTOR >
CN300 1-774-701-21 PIN, CONNECTOR 16P
CN350 1-820-611-11 CONNECTOR, BOARD TO BOARD 28P
* CN801 1-564-710-11 PIN, CONNECTOR (SMALL TYPE) 8P
* CN802 1-770-524-31 CONNECTOR, FFC/FPC 17P
CN803 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CNJ400 1-580-907-41 PLUG, CONNECTOR 8P (BUS CONTROL IN)
< DIODE >
D2 6-501-734-01 DIODE MAZ8056GMLS0
D101 6-501-743-01 DIODE MAZ8068GMLS0
D102 6-501-743-01 DIODE MAZ8068GMLS0
D103 6-501-782-01 DIODE MAZ8180GMLS0
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
