Sony CDX-M50IP - Electrical Parts List (Main Board - Part 4); Main Board Parts List (Part 4)

45
CDX-M50IP/MR50IP
L301 1-216-864-11 SHORT CHIP 0
L302 1-216-864-11 SHORT CHIP 0
L303 1-216-864-11 SHORT CHIP 0
L500 1-469-844-11 INDUCTOR 2.2uH
L801 1-414-595-11 INDUCTOR, FERRITE BEAD
L901 1-216-295-11 SHORT CHIP 0
< TRANSISTOR >
Q1 8-729-038-28 TRANSISTOR RT1N441C-TP-1 (MR50IP)
Q3 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q50 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R (MR50IP)
Q401 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q420 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q430 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q440 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q450 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q460 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q470 6-551-856-01 TRANSISTOR LTC614TKFP8T146
Q491 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q492 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q496 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q501 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q589 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q590 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q600 8-729-047-76 TRANSISTOR FMC2A-T148
Q601 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q605 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q701 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q702 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q703 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q801 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q802 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q803 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q804 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q806 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q824 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R1 1-216-809-11 METAL CHIP 100 5% 1/10W
(MR50IP)
R2 1-216-839-11 METAL CHIP 33K 5% 1/10W
R3 1-216-843-11 METAL CHIP 68K 5% 1/10W
R4 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5 1-216-843-11 METAL CHIP 68K 5% 1/10W
R6 1-414-595-11 INDUCTOR, FERRITE BEAD
R7 1-414-595-11 INDUCTOR, FERRITE BEAD
R8 1-216-839-11 METAL CHIP 33K 5% 1/10W
(MR50IP)
R9 1-216-843-11 METAL CHIP 68K 5% 1/10W
(MR50IP)
R10 1-216-821-11 METAL CHIP 1K 5% 1/10W
R11 1-216-864-11 SHORT CHIP 0 (MR50IP)
R12 1-414-595-11 INDUCTOR, FERRITE BEAD
R13 1-414-595-11 INDUCTOR, FERRITE BEAD
R52 1-216-845-11 METAL CHIP 100K 5% 1/10W
(MR50IP)
R53 1-216-797-11 METAL CHIP 10 5% 1/10W
(MR50IP)
R54 1-414-595-11 INDUCTOR, FERRITE BEAD (MR50IP)
R55 1-216-797-11 METAL CHIP 10 5% 1/10W
(MR50IP)
R57 1-216-833-11 METAL CHIP 10K 5% 1/10W
(MR50IP)
R58 1-216-821-11 METAL CHIP 1K 5% 1/10W
(MR50IP)
R301 1-216-811-11 METAL CHIP 150 5% 1/10W
R302 1-216-841-11 METAL CHIP 47K 5% 1/10W
R351 1-216-845-11 METAL CHIP 100K 5% 1/10W
R355 1-216-834-11 METAL CHIP 12K 5% 1/10W
R356 1-216-834-11 METAL CHIP 12K 5% 1/10W
R357 1-216-817-11 METAL CHIP 470 5% 1/10W
R358 1-216-817-11 METAL CHIP 470 5% 1/10W
R361 1-216-821-11 METAL CHIP 1K 5% 1/10W
R370 1-216-809-11 METAL CHIP 100 5% 1/10W
R371 1-216-809-11 METAL CHIP 100 5% 1/10W
R401 1-216-821-11 METAL CHIP 1K 5% 1/10W
R402 1-216-821-11 METAL CHIP 1K 5% 1/10W
R416 1-216-821-11 METAL CHIP 1K 5% 1/10W
R417 1-216-833-11 METAL CHIP 10K 5% 1/10W
R418 1-216-821-11 METAL CHIP 1K 5% 1/10W
R419 1-216-833-11 METAL CHIP 10K 5% 1/10W
R421 1-216-813-11 METAL CHIP 220 5% 1/10W
R422 1-216-833-11 METAL CHIP 10K 5% 1/10W
R431 1-216-813-11 METAL CHIP 220 5% 1/10W
R432 1-216-833-11 METAL CHIP 10K 5% 1/10W
R433 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R440 1-216-864-11 SHORT CHIP 0
R441 1-216-813-11 METAL CHIP 220 5% 1/10W
R442 1-216-833-11 METAL CHIP 10K 5% 1/10W
R451 1-216-813-11 METAL CHIP 220 5% 1/10W
R452 1-216-833-11 METAL CHIP 10K 5% 1/10W
R455 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R461 1-216-813-11 METAL CHIP 220 5% 1/10W
R462 1-216-833-11 METAL CHIP 10K 5% 1/10W
R471 1-216-813-11 METAL CHIP 220 5% 1/10W
R472 1-216-833-11 METAL CHIP 10K 5% 1/10W
R480 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R481 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R482 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R483 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R484 1-216-821-11 METAL CHIP 1K 5% 1/10W
R491 1-216-805-11 METAL CHIP 47 5% 1/10W
R494 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R495 1-216-841-11 METAL CHIP 47K 5% 1/10W
R500 1-216-817-11 METAL CHIP 470 5% 1/10W
R501 1-216-845-11 METAL CHIP 100K 5% 1/10W
(M50IP)
R502 1-216-845-11 METAL CHIP 100K 5% 1/10W
(MR50IP)
R503 1-216-845-11 METAL CHIP 100K 5% 1/10W
R505 1-216-845-11 METAL CHIP 100K 5% 1/10W
(MR50IP)
R507 1-216-845-11 METAL CHIP 100K 5% 1/10W
(M50IP)
R509 1-216-845-11 METAL CHIP 100K 5% 1/10W
R510 1-216-833-11 METAL CHIP 10K 5% 1/10W
R512 1-216-845-11 METAL CHIP 100K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
