Sony CFD-G55 - Page 45

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
45
CFD-G55
< RESISTOR >
R701 1-216-841-11 METAL CHIP 47K 5% 1/16W
R702 1-216-835-11 METAL CHIP 15K 5% 1/16W
R703 1-216-835-11 METAL CHIP 15K 5% 1/16W
R704 1-216-835-11 METAL CHIP 15K 5% 1/16W
R705 1-216-835-11 METAL CHIP 15K 5% 1/16W
R706 1-216-841-11 METAL CHIP 47K 5% 1/16W
R707 1-216-797-11 METAL CHIP 10 5% 1/16W
R708 1-216-833-11 METAL CHIP 10K 5% 1/16W
R709 1-216-837-11 METAL CHIP 22K 5% 1/16W
R710 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R711 1-216-815-11 METAL CHIP 330 5% 1/16W
R712 1-216-809-11 METAL CHIP 100 5% 1/16W
R714 1-216-811-11 METAL CHIP 150 5% 1/16W
R715 1-216-811-11 METAL CHIP 150 5% 1/16W
R716 1-216-821-11 METAL CHIP 1K 5% 1/16W
R717 1-216-821-11 METAL CHIP 1K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R719 1-216-809-11 METAL CHIP 100 5% 1/16W
R720 1-216-809-11 METAL CHIP 100 5% 1/16W
R721 1-216-821-11 METAL CHIP 1K 5% 1/16W
R722 1-216-809-11 METAL CHIP 100 5% 1/16W
R723 1-216-809-11 METAL CHIP 100 5% 1/16W
R724 1-216-841-11 METAL CHIP 47K 5% 1/16W
R725 1-216-819-11 METAL CHIP 680 5% 1/16W
R726 1-216-819-11 METAL CHIP 680 5% 1/16W
R727 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R728 1-216-833-11 METAL CHIP 10K 5% 1/16W
R729 1-216-813-11 METAL CHIP 220 5% 1/16W
R730 1-216-821-11 METAL CHIP 1K 5% 1/16W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R732 1-216-841-11 METAL CHIP 47K 5% 1/16W
R741 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R743 1-218-867-11 RES-CHIP 6.8K 5% 1/10W
R744 1-216-845-11 METAL CHIP 100K 5% 1/16W
< SWITCH >
S701 1-571-936-11 SWITCH, LEAF (LIMIT IN)
< VIBRATOR >
X701 1-781-801-21 VIBRATOR, CERAMIC 16.93MHz
**************************************************************
* 1-683-710-11 CONTROL (CD) BOARD
*******************
< CABLE HOLDER >
* KH403 1-573-287-11 HOLDER, CABLE 2P
< RESISTOR >
R404 1-216-821-11 METAL CHIP 1K 5% 1/16W
R405 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R406 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R407 1-216-821-11 METAL CHIP 1K 5% 1/16W
R408 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R409 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R410 1-216-837-11 METAL CHIP 22K 5% 1/16W
< SWITCH >
S404 1-771-349-21 SWITCH, TACT (u)
S405 1-771-349-21 SWITCH, TACT (x)
S406 1-771-349-21 SWITCH, TACT (AUTO PRESET/BAND)
S407 1-771-349-21 SWITCH, TACT (PRESET+ >)
S408 1-771-349-21 SWITCH, TACT (PRESET– .)
**************************************************************
* 1-683-708-11 CONTROL (POWER) BOARD
***********************
< CABLE HOLDER >
* KH404 1-565-384-11 HOLDER, CABLE 3P
< RESISTOR >
R401 1-216-817-11 METAL CHIP 470 5% 1/16W
R402 1-216-813-11 METAL CHIP 220 5% 1/16W
R403 1-216-821-11 METAL CHIP 1K 5% 1/16W
< SWITCH >
S401 1-771-349-21 SWITCH, TACT (POWER)
S402 1-771-349-21 SWITCH, TACT (SLEEP)
S403 1-771-349-21 SWITCH, TACT (LINE)
**************************************************************
* 1-683-709-11 CONTROL (VOL) BOARD
********************
< CONNECTOR >
CNP401 1-784-726-11 CONNECTOR, FFC 4P
< DIODE >
D401 8-719-085-33 DIODE SLI-343URCT32WST
(POWER DRIVE WOOFER)
< CABLE HOLDER >
* KH402 1-565-386-11 HOLDER, CABLE 5P
< RESISTOR >
R411 1-216-817-11 METAL CHIP 470 5% 1/16W
R412 1-216-813-11 METAL CHIP 220 5% 1/16W
R413 1-216-821-11 METAL CHIP 1K 5% 1/16W
R414 1-216-821-11 METAL CHIP 1K 5% 1/16W
R415 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R416 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R417 1-216-821-11 METAL CHIP 1K 5% 1/16W
R418 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R419 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R420 1-216-837-11 METAL CHIP 22K 5% 1/16W
< SWITCH >
S409 1-771-349-21 SWITCH, TACT (MODE)
S410 1-771-349-21 SWITCH, TACT (TUNE+)
S411 1-771-349-21 SWITCH, TACT (TUNE–)
S412 1-771-349-21 SWITCH, TACT (SOUND)
S413 1-771-349-21 SWITCH, TACT (DISPLAY/ENTER/MEMORY)
S414 1-771-349-21 SWITCH, TACT (VOLUME–)
S415 1-771-349-21 SWITCH, TACT (VOLUME+)
S416 1-771-349-21 SWITCH, TACT (POWER DRIVE WOOFER)
**************************************************************
CD CONTROL (CD) CONTROL (POWER) CONTROL (VOL)
