Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
46
CFD-G55
* 1-683-707-11 HEADPHONE BOARD
*****************
< CONNECTOR >
* CNP391 1-785-657-21 PIN, CONNECTOR (PC BOARD) 5P
* CNP392 1-785-656-21 PIN, CONNECTOR (PC BOARD) 4P
* CNP393 1-785-656-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP394 1-785-656-11 PIN, CONNECTOR (PC BOARD) 4P
< JACK >
J391 1-794-016-11 JACK (i)
< RESISTOR >
R191 1-247-807-31 CARBON 100 5% 1/4W
R192 1-216-821-11 METAL CHIP 1K 5% 1/16W
R291 1-247-807-31 CARBON 100 5% 1/4W
R292 1-216-821-11 METAL CHIP 1K 5% 1/16W
**************************************************************
* A-3178-409-A L-R/REG BOARD, COMPLETE
************************
3-238-232-01 CHASSIS (HS.L)
3-703-150-11 CLAMP
4-960-167-01 SCREW (3X8) (DIA. 10), +WH
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C171 1-126-947-11 ELECT 47uF 20.00% 10V
C172 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C173 1-126-947-11 ELECT 47uF 20.00% 10V
C174 1-126-926-11 ELECT 1000uF 20.00% 10V
C175 1-136-165-00 FILM 0.1uF 5.00% 50V
C176 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C271 1-126-947-11 ELECT 47uF 20.00% 10V
C272 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C273 1-126-947-11 ELECT 47uF 20.00% 10V
C274 1-126-926-11 ELECT 1000uF 20.00% 10V
C275 1-136-165-00 FILM 0.1uF 5.00% 50V
C276 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C371 1-104-665-11 ELECT 100uF 20.00% 10V
C972 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CNP371 1-785-657-21 PIN, CONNECTOR (PC BOARD) 5P
* CNP372 1-785-655-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP373 1-785-657-11 PIN, CONNECTOR (PC BOARD) 5P
< IC >
IC371 8-759-426-51 IC BA5417
< CABLE HOLDER >
* KH374 1-565-385-11 HOLDER, CABLE 4P
< TRANSISTOR >
Q171 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q271 8-729-281-53 TRANSISTOR 2SC1815GR-TPE2
Q971 8-729-037-08 TRANSISTOR KTD2058Y
Q972 8-729-037-08 TRANSISTOR KTD2058Y
< RESISTOR >
R172 1-216-837-11 METAL CHIP 22K 5% 1/16W
R173 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R175 1-216-813-11 METAL CHIP 220 5% 1/16W
R176 1-216-805-11 METAL CHIP 47 5% 1/16W
R177 1-249-389-11 CARBON 4.7 5% 1/4W F
R178 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R272 1-216-837-11 METAL CHIP 22K 5% 1/16W
R273 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R275 1-216-813-11 METAL CHIP 220 5% 1/16W
R276 1-216-805-11 METAL CHIP 47 5% 1/16W
R277 1-249-389-11 CARBON 4.7 5% 1/4W F
R278 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R371 1-216-833-11 METAL CHIP 10K 5% 1/16W
**************************************************************
* A-3021-803-A LCD BOARD, COMPLETE
(including BACK LIGHT Board)
* 1-683-704-11 LCD BOARD
**************************************
3-238-246-01 HOLDER (LCD.944)
3-238-248-01 PLATE (LCD), LIGHT GUIDE
3-240-574-01 SHEET (LCD), DIFFUSION
< CAPACITOR >
C891 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
CNP891 1-784-749-11 CONNECTOR, FFC 27P
< DIODE >
D891 8-719-085-33 DIODE SLI-343URCT32WST (OPR/BATT)
(mounted BACK LIGHT Board)
D893 8-719-059-97 DIODE L-34HD (LCD BACK LIGHT)
< IC >
IC891 8-749-014-88 IC SPS-440-E (g)
< LIQUID CRYSTAL DISPLAY >
LCD891 1-804-641-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R891 1-216-841-11 METAL CHIP 47K 5% 1/16W
R892 1-216-813-11 METAL CHIP 220 5% 1/16W
R893 1-216-821-11 METAL CHIP 1K 5% 1/16W
R894 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R895 1-216-864-11 METAL CHIP 0 5% 1/16W
**************************************************************
HEADPHONE L-R/REG LCD
