Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51
CFD-G55
< TRANSFORMER >
T301 1-416-041-11 TRANSFORMER, BIAS OSCILLATION
**************************************************************
* 1-683-702-11 TRANS BOARD
*************
1-533-233-31 HOLDER, FUSE
< FUSE >
0 F902 1-576-193-11 FUSE 6.3A/125V (US,CND,E92,MX)
0 F902 1-532-504-51 FUSE T4AL/250V (MY,SP)
< TRANSFORMER >
0 T901 1-435-964-11 TRANSFORMER, POWER (US,CND,E92,MX)
0 T901 1-435-965-11 TRANSFORMER, POWER (MY,SP)
**************************************************************
* A-3323-779-A TUNER BOARD, COMPLETE (US,CND,E92,MX)
* A-3323-815-A TUNER BOARD, COMPLETE (MY,SP)
*************************************
< CAPACITOR >
C1 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C4 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C8 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C9 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C10 1-126-960-11 ELECT 1uF 20.00% 50V
C11 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C12 1-126-963-11 ELECT 4.7uF 20.00% 50V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C15 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C18 1-126-934-11 ELECT 220uF 20.00% 10V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C21 1-126-960-11 ELECT 1uF 20.00% 50V
C22 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C23 1-126-960-11 ELECT 1uF 20.00% 50V
C24 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C26 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C27 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C29 1-104-665-11 ELECT 100uF 20.00% 10V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C31 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C32 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C33 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C34 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C37 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C39 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C41 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C42 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C43 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C47 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C49 1-161-051-00 CERAMIC 0.01uF 10% 50V
C51 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C52 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C53 1-136-169-00 FILM 0.22uF 5.00% 50V
C54 1-126-934-11 ELECT 220uF 20.00% 10V
C55 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C56 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C57 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C59 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C60 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C61 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C62 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C63 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C65 1-126-963-11 ELECT 4.7uF 20.00% 50V
C66 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C68 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C77 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C78 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C80 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C95 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< FILTER >
CF2 1-760-233-71 FILTER, CERAMIC
CF4 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
* CNP1 1-564-713-11 PIN, CONNECTOR (SMALL TYPE)11P
< TRIMMER >
CT1 1-141-603-11 CAP, ADJ
CT3 1-141-601-11 CAP, ADJ
< DIODE >
D1 8-719-078-48 DIODE KV1471ETR1-3
D2 8-719-078-48 DIODE KV1471ETR1-3
D3 8-719-050-69 DIODE KV1520NT
D10 8-719-988-61 DIODE 1SS355TE-17
D11 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC1 6-700-512-01 IC TA2149BN
IC2 8-759-483-40 IC LC72137M-TLM
< JUMPER RESISTOR >
JC1 1-216-864-11 METAL CHIP 0 5% 1/16W
JC2 1-216-864-11 METAL CHIP 0 5% 1/16W
JC3 1-216-864-11 METAL CHIP 0 5% 1/16W
JC4 1-216-864-11 METAL CHIP 0 5% 1/16W
JC5 1-216-864-11 METAL CHIP 0 5% 1/16W
JC6 1-216-864-11 METAL CHIP 0 5% 1/16W
JC11 1-216-864-11 METAL CHIP 0 5% 1/16W
JC12 1-216-864-11 METAL CHIP 0 5% 1/16W
JC13 1-216-864-11 METAL CHIP 0 5% 1/16W
JC33 1-216-864-11 METAL CHIP 0 5% 1/16W
JC34 1-216-864-11 METAL CHIP 0 5% 1/16W
TUNERTRANSTC
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
