Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
52
CFD-G55
< COIL >
L1 1-409-775-11 COIL, AIR-CORE
L2 1-416-509-11 COIL, AIR-CORE
L3 1-428-947-11 COIL, FERRITE-ROD ANTENNA
L3 1-754-117-11 ANTENNA, FERRITE-ROD (MW)
L4 1-411-234-21 COIL, AM OSC
L11 1-414-142-11 INDUCTOR 1uH
L21 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R1 1-216-815-11 METAL CHIP 330 5% 1/16W
R2 1-216-817-11 METAL CHIP 470 5% 1/16W
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4 1-216-833-11 METAL CHIP 10K 5% 1/16W
R10 1-216-805-11 METAL CHIP 47 5% 1/16W
R11 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R13 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R24 1-216-813-11 METAL CHIP 220 5% 1/16W
R30 1-216-835-11 METAL CHIP 15K 5% 1/16W
R31 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R32 1-216-845-11 METAL CHIP 100K 5% 1/16W
R40 1-216-849-11 METAL CHIP 220K 5% 1/16W
R41 1-216-833-11 METAL CHIP 10K 5% 1/16W
R50 1-216-821-11 METAL CHIP 1K 5% 1/16W
R51 1-216-833-11 METAL CHIP 10K 5% 1/16W
R52 1-216-864-11 METAL CHIP 0 5% 1/16W
R53 1-216-835-11 METAL CHIP 15K 5% 1/16W
R54 1-216-817-11 METAL CHIP 470 5% 1/16W
R56 1-216-815-11 METAL CHIP 330 5% 1/16W
R58 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R59 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R60 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R61 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R63 1-216-833-11 METAL CHIP 10K 5% 1/16W
R65 1-216-833-11 METAL CHIP 10K 5% 1/16W
R91 1-216-813-11 METAL CHIP 220 5% 1/16W
R92 1-216-813-11 METAL CHIP 220 5% 1/16W
R94 1-216-821-11 METAL CHIP 1K 5% 1/16W
< TRANSFORMER >
T1 1-433-741-11 TRANSFORMER, IF
T2 1-419-465-11 COIL (DET)
< VIBRATOR >
X1 1-795-449-11 VIBRATOR, CRYSTAL 75kHz
**************************************************************
TUNER
MISCELLANEOUS
***************
9 1-823-743-11 CABLE, FLEXIBLE FLAT (27 CORE)
17 1-823-744-11 CABLE, FLEXIBLE FLAT (4 CORE)
58 1-452-899-11 MAGNET
103 1-757-778-11 CABLE, FLEXIBLE FLAT (11 CORE)
123 1-823-742-11 WIRE (FLAT TYPE) (14 CORE)
124 1-757-689-11 CABLE, FLEXIBLE FLAT (16 CORE)
0 251 8-848-483-05 OPTICAL PICK-UP KSS-213R
ANT1 1-501-883-21 ANTENNA, TELESCOPIC
HE301 1-543-876-11 HEAD (ERASE)
HRP301 1-500-691-11 HEAD,MAGNETIC(RECORD/PLAYBACK)
M321 A-3320-446-A MOTOR ASSY (CAPSTAN/REEL)
M701 1-541-328-21 MOTOR, DC (SLED)
S321 1-771-686-11 SWITCH, LEAF (PLAY)
S322 1-762-679-11 SWITCH, LEAF (MOTOR SW)
S801 1-692-960-11 SWITCH, PUSH (1 KEY)
(
Z
PUSH OPEN/CLOSE)
SP391 1-544-790-11 SPEAKER (10cm)
SP392 1-544-790-11 SPEAKER (10cm)
SP393 1-825-030-11 SPEAKER (8cm) (WOOFER)
**************************************************************
ACCESSORIES
************
0 1-557-287-11 CORD, POWER (E92,MX)
0 1-575-131-11 CORD, POWER (MY, SP)
0 1-783-878-11 CORD, POWER (US,CND)
3-241-310-11 MANUAL, INSTRUCTION (US,CND,E92,MX)
(ENGLISH)
3-241-310-21 MANUAL, INSTRUCTION (CND) (FRENCH)
3-241-310-31 MANUAL, INSTRUCTION (E92,MX) (SPANISH)
3-241-310-41 MANUAL, INSTRUCTION (MY,SP) (ENGLISH)
3-241-310-51 MANUAL, INSTRUCTION (MY,SP) (SPANISH)
3-027-153-01 LID, REMOTE COMMANDER (FOR RMT-CG35A)
A-3013-979-A REMOTE COMMANDER RMT-CG35A
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
