12
CFD-RS60CP
3-12. R/P HEAD (HRP301), ERASE HEAD (HE301), TC BOARD
3-11. CD BLOCK ASSY
4
CD block assy
3
CD cover
two claws
two claws
1
two
screws
(+PWH tapping (B2.6
)
)
2
two
screws
(+PWH tapping (B2.6
)
)
4
two claws
1
R/P head (HRP301)
2
erase head (HE301)
3
screw
5
Remove the four solderings.
6
TC boar
d
