Sony CFD-RS60CP Service Manual

62
CFD-RS60CP
MAIN
R869 1-216-821-11 METAL CHIP 1K 5% 1/10W
R870 1-216-821-11 METAL CHIP 1K 5% 1/10W
R871 1-216-821-11 METAL CHIP 1K 5% 1/10W
R872 1-216-821-11 METAL CHIP 1K 5% 1/10W
R874 1-216-817-11 METAL CHIP 470 5% 1/10W
R875 1-216-833-11 METAL CHIP 10K 5% 1/10W
R877 1-216-821-11 METAL CHIP 1K 5% 1/10W
R878 1-216-821-11 METAL CHIP 1K 5% 1/10W
R879 1-216-821-11 METAL CHIP 1K 5% 1/10W
R880 1-216-809-11 METAL CHIP 100 5% 1/10W
R881 1-216-809-11 METAL CHIP 100 5% 1/10W
R882 1-216-809-11 METAL CHIP 100 5% 1/10W
R883 1-216-809-11 METAL CHIP 100 5% 1/10W
R884 1-216-809-11 METAL CHIP 100 5% 1/10W
R885 1-216-833-11 METAL CHIP 10K 5% 1/10W
R886 1-216-845-11 METAL CHIP 100K 5% 1/10W
R887 1-216-853-11 METAL CHIP 470K 5% 1/10W
R888 1-216-837-11 METAL CHIP 22K 5% 1/10W
R889 1-216-837-11 METAL CHIP 22K 5% 1/10W
R890 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R891 1-216-857-11 METAL CHIP 1M 5% 1/10W
R892 1-216-864-11 SHORT CHIP 0
R893 1-216-845-11 METAL CHIP 100K 5% 1/10W
R894 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R895 1-216-833-11 METAL CHIP 10K 5% 1/10W
R896 1-216-845-11 METAL CHIP 100K 5% 1/10W
R897 1-216-821-11 METAL CHIP 1K 5% 1/10W
R898 1-216-845-11 METAL CHIP 100K 5% 1/10W
R899 1-216-837-11 METAL CHIP 22K 5% 1/10W
R901 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R902 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R903 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R904 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R905 1-216-841-11 METAL CHIP 47K 5% 1/10W
R906 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R907 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R908 1-216-833-11 METAL CHIP 10K 5% 1/10W
R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
R910 1-216-821-11 METAL CHIP 1K 5% 1/10W
R911 1-216-821-11 METAL CHIP 1K 5% 1/10W
R912 1-216-821-11 METAL CHIP 1K 5% 1/10W
R913 1-216-821-11 METAL CHIP 1K 5% 1/10W
R914 1-216-821-11 METAL CHIP 1K 5% 1/10W
R915 1-216-809-11 METAL CHIP 100 5% 1/10W
R916 1-216-817-11 METAL CHIP 470 5% 1/10W
R917 1-216-817-11 METAL CHIP 470 5% 1/10W
R918 1-216-817-11 METAL CHIP 470 5% 1/10W
R919 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R920 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R921 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R922 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R923 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R924 1-216-809-11 METAL CHIP 100 5% 1/10W
R925 1-216-809-11 METAL CHIP 100 5% 1/10W
R926 1-216-833-11 METAL CHIP 10K 5% 1/10W
R927 1-216-809-11 METAL CHIP 100 5% 1/10W
< VIBRATOR >
X801 1-813-940-21 PIEZOELECTRIC OSCILLATOR (5.53MHz)
*************************************************************
A-1317-459-A POWER BOARD, COMPLETE
***********************
1-533-233-31 HOLDER, FUSE
< CAPACITOR >
C951 1-126-947-11 ELECT 47uF 20% 35V
C952 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C953 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C954 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C955 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C956 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C957 1-126-768-11 ELECT 2200uF 20% 16V
< CONNECTOR >
CN952 1-815-446-11 PIN, CONNECTOR (PWB) 5P
< DIODE >
D951 6-501-569-01 DIODE 1N5401-C352
D952 6-501-569-01 DIODE 1N5401-C352
D953 6-501-569-01 DIODE 1N5401-C352
D954 6-501-569-01 DIODE 1N5401-C352
*************************************************************
A-1317-468-A POWER KEY BOARD, COMPLETE
***************************
< RESISTOR >
R418 1-216-821-11 METAL CHIP 1K 5% 1/10W
R419 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R420 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R421 1-216-821-11 METAL CHIP 1K 5% 1/10W
R422 1-216-821-11 METAL CHIP 1K 5% 1/10W
R423 1-216-817-11 METAL CHIP 470 5% 1/10W
R424 1-216-813-11 METAL CHIP 220 5% 1/10W
< SWITCH >
S413 1-786-726-11 SWITCH, TACTILE (USB)
S414 1-786-726-11 SWITCH, TACTILE (TAPE)
S415 1-786-726-11 SWITCH, TACTILE (RADIO/AUTO PRESET)
S416 1-786-726-11 SWITCH, TACTILE (CD)
S417 1-786-726-11 SWITCH, TACTILE (SLEEP)
S418 1-786-726-11 SWITCH, TACTILE (OPERATE)
*************************************************************
A-1108-791-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-104-658-11 ELECT 100uF 20% 10V
C103 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C104 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C105 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
POWER POWER KEY TC

Sony CFD-RS60CP Specifications

General

Radio type	Portable
Tuner type	Digital
AM band range	530 - 1611 kHz
FM band range	87.5 - 108 MHz
Backlight	Yes
Product color	Black
Dimensions (WxDxH)	420 x 159 x 260 mm

Weight and Dimensions

Weight	3700 g
