Sony CFD-S700 - Optical Pick-up and Related Parts Disassembly

11
CFD-S700
3-12. CD Board
3-11. Belt, M801 (Capstan/Reel Motor), HRP301 (Magnetic Head)
mechanism deck
1 two screws
(B 2.6 × 5)
4 M801
(capstan/reel motor
)
2
3 belt
5 claws
6 HRP301 (magnetic head)
2 screw (BVTT 2x6)
3 flexible flat cable
(16 core)
1 Remove soldering
from the four points.
4 CD board
