Sony CFD-S700 - Printed Wiring Boards - POWER SUPPLY Section

CFD-S700
29 29
6-15. Printed Wiring Boards — POWER SUPPLY Section — • Refer to page 17 for Circuit Boards Location and page 20 for Common Note on Printed Wiring Boards.
• : Uses unleaded solder.
220-240V
110-120V
S1
VOLTAGE
SELECTOR
DRY BATTERY
SIZE"D"
(IEC DESIGNATION LR20)
3PCS. 4.5V
DRY BATTERY
SIZE"D"
(IEC DESIGNATION LR20)
3PCS. 4.5V
TO
MAIN
BOARD
KH321
(Page 22)
AC IN
T901
POWER
TRANSFORMER
CNP905
F902
CND,E15,E92,SP,MX
F901
E15
SELECTION
BOARD
E15
Ver 1.1 2003.03
