CFD-S700
17 17
Pin No. Pin Name I/O Pin Description
75 X2 O Main system oscillation output (4.19 MHz)
76 RST I System reset input
77 ISS1 O ISS1 output Not used. (Open)
78 ISS2 O ISS2 output Not used. (Open)
79 SCL O EEPROM clock output
80 SDA I/O EEPROM input/output
6-2. Circuit Boards Location
CONTROL (1) board
CONTROL (2) board
CONTROL (3) board
CD board
BATTERY (2) boar
BATTERY (1) board
POWER AMP board
MAIN board
PRE board
POWER board
SELECTION board
INLET board
Ver 1.1 2003.03
