42
CFD-S700
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3347-879-A CONTROL (2) BOARD, COMPLETE (EXCEPT E15)
***************************
* A-3363-904-A CONTROL (2) BOARD, COMPLETE (E15)
***************************
< CONNECTOR >
* CNP404 1-815-553-11 PIN, CONNECTOR (PWB) 5P
< IC >
IC401 8-749-018-72 IC SPS-442-E
< RESISTOR >
R409 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R410 1-216-821-11 METAL CHIP 1K 5% 1/10W
(EXCEPT E15)
R412 1-216-821-11 METAL CHIP 1K 5% 1/10W
R437 1-216-849-11 METAL CHIP 220K 5% 1/10W
R438 1-216-845-11 METAL CHIP 100K 5% 1/10W
R440 1-216-813-11 METAL CHIP 220 5% 1/10W
R450 1-216-821-11 METAL CHIP 1K 5% 1/10W
R451 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R452 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S407 1-786-050-21 SWITCH, KEY BOARD (CD)
S408 1-786-050-21 SWITCH, KEY BOARD (TAPE)
S409 1-786-050-21 SWITCH, KEY BOARD
(RADIO BAND/AUTO PRESET)
**************************************************************
* A-3347-885-A CONTROL (3) BOARD, COMPLETE (EXCEPT E15)
***************************
* A-3363-906-A CONTROL (3) BOARD, COMPLETE (E15)
***************************
< DIODE >
D451 8-719-059-97 DIODE L-34HD (OPR/BATT)
< CABLE HOLDER >
* KH405 1-565-384-11 HOLDER, CABLE 3P
< RESISTOR >
R414 1-216-821-11 METAL CHIP 1K 5% 1/10W
R415 1-216-837-11 METAL CHIP 22K 5% 1/10W
R416 1-216-841-11 METAL CHIP 47K 5% 1/10W
R435 1-216-813-11 METAL CHIP 220 5% 1/10W
R436 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R443 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R444 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R445 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R474 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R475 1-216-833-11 METAL CHIP 10K 5% 1/10W
R476 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S411 1-786-050-21 SWITCH, KEY BOARD (DISPLAY ENT/MEMORY)
S412 1-786-050-21 SWITCH, KEY BOARD (MODE)
**************************************************************
* A-3347-884-A INLET BOARD, COMPLETE
(included POWER Board)(E92,MX)
*********************
* A-3363-900-A INLET BOARD, COMPLETE
(included POWER Board)(CND)
*********************
* A-3383-672-A INLET BOARD, COMPLETE
(included POWER Board)(SP)
*********************
* A-3347-887-A INLET BOARD, COMPLETE
(included POWER Board)(E15)
*********************
1-533-233-31 FUSE HOLDER
< CAPACITOR >
C901 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C902 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C903 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C904 1-162-995-11 CERAMIC CHIP 0.022uF 50V
C906 1-126-964-11 ELECT 10uF 20.00% 50V
< JACK >
0CNJ901 1-526-818-11 INLET, AC ( - AC IN)(E92,MX)
0CNJ901 1-526-838-11 INLET, AC ( - AC IN)(E15,SP)
0CNJ901 1-540-009-11 INLET, AC ( - AC IN)(CND)
< CONNECTOR >
* CNP901 1-815-444-11 PIN, CONNECTOR (PWB) 3P
* CNP902 1-815-552-21 PIN, CONNECTOR (PWB) 4P
< DIODE >
D901 8-719-046-07 DIODE 2A02M
D902 8-719-046-07 DIODE 2A02M
D903 8-719-046-07 DIODE 2A02M
D904 8-719-046-07 DIODE 2A02M
< FUSE >
0F901 1-533-462-11 FUSE (0.5A/250V)(E15)
0F902 1-533-470-11 FUSE (3.15A/250V)(E15,SP)
0F902 1-533-419-11 FUSE (4A/125V)(CND,E92,MX)
< CABLE HOLDER >
* KH903 1-573-287-11 HOLDER, CABLE 2P
**************************************************************
* A-3347-876-A MAIN BOARD, COMPLETE (CND,E92,MX)
*********************
* A-3347-886-A MAIN BOARD, COMPLETE (E15)
*********************
* A-3347-892-A MAIN BOARD, COMPLETE (SP)
*********************
* 1-757-560-11 CABLE, FLEXIBLE FLAT (11 CORE)
* 1-757-561-11 CABLE, FLEXIBLE FLAT (14 CORE)
3-224-365-11 HOLDER (LCD)
7-685-646-79 SCREW, TAPPING +BV 3X8
3-363-898-01 CUSHION
3-831-441-99 CUSHION (A)
CONTROL (2) CONTROL (3)
MAININLET
Ver 1.1 2003.03
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
