44
CFD-S700
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< FILTER >
CF2 1-795-035-11 FILTER, CERAMIC
CF4 1-781-962-21 FILTER, CERAMIC
< CONNECTOR >
CNP805 1-691-040-31 CONNECTOR, FFC 8P
< TRIMMER >
CT1 1-141-603-21 CAP, ADJ
CT3 1-141-601-21 CAP, ADJ
< DIODE >
D1 8-719-078-48 DIODE KV1471ETR1-3
D2 8-719-078-48 DIODE KV1471ETR1-3
D3 8-719-050-69 DIODE KV1520NT
D10 8-719-988-61 DIODE 1SS355TE-17
D11 8-719-988-61 DIODE 1SS355TE-17
D322 8-719-988-61 DIODE 1SS355TE-17
D324 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-083-39 DIODE KDZ5.1V-RTK
D802 8-719-082-07 DIODE KDS121-RTK
D803 8-719-082-07 DIODE KDS121-RTK
D804 8-719-082-07 DIODE KDS121-RTK
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-083-93 DIODE KDS120-RTK
D951 8-719-988-61 DIODE 1SS355TE-17
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-056-84 DIODE UDZSTE-177.5B
D957 8-719-082-09 DIODE KDZ3.9V-RTK
< IC >
IC1 8-759-662-67 IC TA2149N
IC2 8-759-483-40 IC LC72137M-TLM
IC302 8-759-539-45 IC M62429P
IC801 6-703-773-01 IC S-80828CNNB-B8N-T2G (EXCEPT E15)
IC801 8-759-658-46 IC S-81233SGY-Z (E15)
IC802 6-800-608-01 IC uPD789477GC-A06-8BT
IC803 8-759-487-03 IC BR24C01AF-WE2
IC804 8-759-645-87 IC PST9128-T
< IC LINK >
0ICP301 1-533-674-11 IC LINK 0.5A 50V
< JACK >
J321 1-568-267-11 JACK( i )
< JUMPER RESISTOR >
JC1 1-216-864-11 METAL CHIP 0 5% 1/10W
JC2 1-216-864-11 METAL CHIP 0 5% 1/10W
JC3 1-216-864-11 METAL CHIP 0 5% 1/10W
JC4 1-216-864-11 METAL CHIP 0 5% 1/10W
JC5 1-216-864-11 METAL CHIP 0 5% 1/10W
JC6 1-216-864-11 METAL CHIP 0 5% 1/10W
JC11 1-216-864-11 METAL CHIP 0 5% 1/10W
JC12 1-216-864-11 METAL CHIP 0 5% 1/10W
JC13 1-216-864-11 METAL CHIP 0 5% 1/10W
JC24 1-216-864-11 METAL CHIP 0 5% 1/10W
JC302 1-216-864-11 METAL CHIP 0 5% 1/10W
JC303 1-216-864-11 METAL CHIP 0 5% 1/10W
JC304 1-216-864-11 METAL CHIP 0 5% 1/10W
JC305 1-216-864-11 METAL CHIP 0 5% 1/10W
JC306 1-216-864-11 METAL CHIP 0 5% 1/10W
JC307 1-216-864-11 METAL CHIP 0 5% 1/10W
JC801 1-216-864-11 METAL CHIP 0 5% 1/10W
< CABLE HOLDER >
* KH321 1-565-385-11 HOLDER, CABLE 4P
* KH803 1-573-287-11 HOLDER, CABLE 2P
< COIL >
L1 1-409-775-21 COIL, AIR-CORE
L2 1-416-509-11 COIL, AIR-CORE
L3 1-424-708-11 COIL, FERRITE-ROD ANTENNA
L4 1-411-234-21 COIL, AM OSC
L21 1-410-509-11 INDUCTOR 10uH
L801 1-414-137-31 INDUCTOR 0.22uH
L802 1-410-521-11 INDUCTOR 100uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-804-243-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q122 8-729-054-58 TRANSISTOR KTC4075-RTK
Q124 8-729-054-24 TRANSISTOR KRC410-RTK
Q125 8-729-054-58 TRANSISTOR KTC4075-RTK
Q222 8-729-054-58 TRANSISTOR KTC4075-RTK
Q224 8-729-054-24 TRANSISTOR KRC410-RTK
Q225 8-729-054-58 TRANSISTOR KTC4075-RTK
Q301 8-729-054-58 TRANSISTOR KTC4075-RTK
Q801 8-729-054-21 TRANSISTOR KRC407-RTK
Q804 8-729-054-07 TRANSISTOR KRA307-RTK
Q806 8-729-054-07 TRANSISTOR KRA307-RTK
Q807 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q808 8-729-054-21 TRANSISTOR KRC407-RTK
Q812 8-729-054-14 TRANSISTOR KRA314-RTK
Q813 8-729-054-21 TRANSISTOR KRC407-RTK
Q814 8-729-054-21 TRANSISTOR KRC407-RTK
Q817 8-729-055-41 TRANSISTOR KTB1241Y-AT
Q818 8-729-054-21 TRANSISTOR KRC407-RTK
Q819 8-729-054-18 TRANSISTOR KRC404-RTK
Q951 8-729-054-15 TRANSISTOR KRC401-RTK
Q952 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q953 8-729-029-09 TRANSISTOR DTC143EU-T106
Q955 8-729-021-82 TRANSISTOR 2SD2396K
Q957 8-729-036-86 TRANSISTOR KTC3203Y-AT
< RESISTOR >
R1 1-216-813-11 METAL CHIP 220 5% 1/10W
R2 1-216-817-11 METAL CHIP 470 5% 1/10W
R3 1-216-833-11 METAL CHIP 10K 5% 1/10W
R4 1-216-833-11 METAL CHIP 10K 5% 1/10W
R5 1-216-809-11 METAL CHIP 100 5% 1/10W
R9 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R10 1-216-805-11 METAL CHIP 47 5% 1/10W
R11 1-216-821-11 METAL CHIP 1K 5% 1/10W
R13 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
Ver 1.1 2003.03
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
