– 6 –
2-3. TAPE MECHANISM BLOCK
2-4. TUNER, AC, SECOND BOARD
1
BVTP 3x10
2
CN301
4
tape mechanism block
3
CN601
2
BVTP 3x10
4
CN1
7
CN901
6
CN911
5
TUNER board
0
AC board
!¡
SECOND board
3
BVTP 3x10
8
BVTP 3x10
9
BVTP 3x10
1
knob (FINE)
