– 25 –
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
* 1-670-175-11 AC BOARD
*********
< CAPACITOR >
C909 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
* CN901 1-691-573-11 PIN, CONNECTOR (PC BOARD) 2P
< AC INLET >
! J901 1-526-838-11 INLET, AC 2P (⁄ AC IN)
*************************************************************
* A-3321-332-A AUDIO BOARD, COMPLETE
**********************
3-025-541-01 LEVER (FUNCTION)
< CAPACITOR >
C101 1-124-903-11 ELECT 1uF 20% 50V
C102 1-162-294-31 CERAMIC 0.001uF 10% 50V
C103 1-124-443-00 ELECT 100uF 20% 10V
C104 1-162-843-11 CERAMIC 0.022uF 10% 16V
C105 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C111 1-126-956-11 ELECT 0.1uF 20% 50V
C115 1-124-252-00 ELECT 0.33uF 20% 50V
C116 1-162-306-11 CERAMIC 0.01uF 30% 16V
C151 1-136-160-00 FILM 0.039uF 5% 50V
C152 1-136-165-00 FILM 0.1uF 5% 50V
C191 1-124-473-11 ELECT 1000uF 20% 10V
C197 1-136-165-00 FILM 0.1uF 5% 50V
C201 1-124-903-11 ELECT 1uF 20% 50V
C202 1-162-294-31 CERAMIC 0.001uF 10% 50V
C203 1-124-443-00 ELECT 100uF 20% 10V
C204 1-162-843-11 CERAMIC 0.022uF 10% 16V
C205 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C211 1-126-956-11 ELECT 0.1uF 20% 50V
C215 1-124-252-00 ELECT 0.33uF 20% 50V
C216 1-162-306-11 CERAMIC 0.01uF 30% 16V
C251 1-136-160-00 FILM 0.039uF 5% 50V
C252 1-136-165-00 FILM 0.1uF 5% 50V
C291 1-124-473-11 ELECT 1000uF 20% 10V
C297 1-136-165-00 FILM 0.1uF 5% 50V
C301 1-126-941-11 ELECT 470uF 20% 16V
C302 1-104-664-11 ELECT 47uF 20% 10V
C304 1-162-294-31 CERAMIC 0.001uF 10% 50V
C306 1-124-907-11 ELECT 10uF 20% 50V
C311 1-161-494-00 CERAMIC 0.022uF 25V
C312 1-161-494-00 CERAMIC 0.022uF 25V
C315 1-124-907-11 ELECT 10uF 20% 50V
C340 1-162-294-31 CERAMIC 0.001uF 10% 50V
C342 1-130-481-00 MYLAR 0.0068uF 5% 50V
C344 1-104-664-11 ELECT 47uF 20% 10V
C351 1-124-907-11 ELECT 10uF 20% 50V
C352 1-126-233-11 ELECT 22uF 20% 50V
C353 1-124-443-00 ELECT 100uF 20% 10V
C391 1-104-666-11 ELECT 220uF 20% 10V
C392 1-162-294-31 CERAMIC 0.001uF 10% 50V
C393 1-126-961-11 ELECT 2.2uF 20% 50V
C394 1-162-294-31 CERAMIC 0.001uF 10% 50V
C395 1-162-294-31 CERAMIC 0.001uF 10% 50V
C396 1-124-902-00 ELECT 0.47uF 20% 50V
C910 1-126-944-11 ELECT 3300uF 20% 16V
C911 1-162-294-31 CERAMIC 0.001uF 10% 50V
C914 1-136-683-11 FILM 0.0056uF 5% 100V
C951 1-162-306-11 CERAMIC 0.01uF 30% 16V
C952 1-104-664-11 ELECT 47uF 20% 10V
C953 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN301 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
* CN305 1-568-271-11 SOCKET, CONNECTOR 5P
* CN311 1-573-287-11 HOLDER, CABLE 2P
* CN341 1-691-574-11 PIN, CONNECTOR (PC BOARD) 3P
CN601 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
* CN911 1-691-573-11 PIN, CONNECTOR (PC BOARD) 2P
CN912 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
* CN913 1-573-287-11 HOLDER, CABLE 2P
< DIODE >
D351 8-719-911-19 DIODE 1SS133T-72
D352 8-719-123-54 DIODE RD5.6ES-T2B
D353 8-719-911-19 DIODE 1SS133T-72
< IC >
IC301 8-759-978-54 IC BA3420AL
IC305 8-759-543-56 IC LA4601N
AC AUDIO
