Sony CFS-B5LMK2

– 26 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< JACK >
J301 1-566-891-11 JACK (2)
< COIL >
L101 1-410-324-11 INDUCTOR 4.7uH
L201 1-410-324-11 INDUCTOR 4.7uH
< TRANSISTOR >
Q151 8-729-036-80 TRANSISTOR KRC110M-AT
Q251 8-729-036-80 TRANSISTOR KRC110M-AT
Q340 8-729-036-89 TRANSISTOR KTC3198GR-A
Q341 8-729-037-34 TRANSISTOR KRA107M-AT
Q351 8-729-037-34 TRANSISTOR KRA107M-AT
Q951 8-729-036-89 TRANSISTOR KTC3198GR-A
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W
R102 1-249-427-11 CARBON 6.8K 5% 1/4W
R103 1-249-401-11 CARBON 47 5% 1/4W
R104 1-249-437-11 CARBON 47K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R111 1-249-433-11 CARBON 22K 5% 1/4W
R112 1-249-417-11 CARBON 1K 5% 1/4W
R113 1-249-417-11 CARBON 1K 5% 1/4W
R115 1-249-429-11 CARBON 10K 5% 1/4W
R117 1-249-425-11 CARBON 4.7K 5% 1/4W
R118 1-247-843-11 CARBON 3.3K 5% 1/4W
R150 1-249-421-11 CARBON 2.2K 5% 1/4W
R191 1-247-807-11 CARBON 100 5% 1/4W
R196 1-249-417-11 CARBON 1K 5% 1/4W
R201 1-249-417-11 CARBON 1K 5% 1/4W
R202 1-249-427-11 CARBON 6.8K 5% 1/4W
R203 1-249-401-11 CARBON 47 5% 1/4W
R204 1-249-437-11 CARBON 47K 5% 1/4W
R205 1-249-429-11 CARBON 10K 5% 1/4W
R211 1-249-433-11 CARBON 22K 5% 1/4W
R212 1-249-417-11 CARBON 1K 5% 1/4W
R213 1-249-417-11 CARBON 1K 5% 1/4W
R215 1-249-429-11 CARBON 10K 5% 1/4W
R217 1-249-425-11 CARBON 4.7K 5% 1/4W
R218 1-247-843-11 CARBON 3.3K 5% 1/4W
R250 1-249-421-11 CARBON 2.2K 5% 1/4W
R291 1-247-807-11 CARBON 100 5% 1/4W
R296 1-249-417-11 CARBON 1K 5% 1/4W
R301 1-249-407-11 CARBON 150 5% 1/4W
R306 1-249-433-11 CARBON 22K 5% 1/4W
R311 1-249-429-11 CARBON 10K 5% 1/4W
R314 1-249-417-11 CARBON 1K 5% 1/4W
R315 1-249-421-11 CARBON 2.2K 5% 1/4W
R341 1-249-393-11 CARBON 10 5% 1/4W
R342 1-249-435-11 CARBON 33K 5% 1/4W
R345 1-249-398-11 CARBON 27 5% 1/4W
R349 1-249-425-11 CARBON 4.7K 5% 1/4W
R351 1-249-417-11 CARBON 1K 5% 1/4W
R352 1-249-417-11 CARBON 1K 5% 1/4W
R353 1-249-437-11 CARBON 47K 5% 1/4W
R355 1-249-441-11 CARBON 100K 5% 1/4W
R391 1-247-843-11 CARBON 3.3K 5% 1/4W
R911 1-249-417-11 CARBON 1K 5% 1/4W
R912 1-249-411-11 CARBON 330 5% 1/4W
< VARIABLE RESISTOR >
RV351 1-225-638-11 RES, VAR, CARBON 20K/20K (VOLUME)
RV352 1-225-639-11 RES, VAR, CARBON 20K/20K (HYPER TREBLE)
RV353 1-225-640-11 RES, VAR, CARBON 100K/100K (MEGA BASS)
< SWITCH >
S301 1-571-472-11 SWITCH, SLIDE (REC/PB)
S302 1-570-729-11 SWITCH, LEVER SLIDE (FUNCTION)
< TRANSFORMER >
T301 1-433-268-00 TRANSFORMER, BIAS OSCILLATOR
*************************************************************
* 1-670-172-21 BATTERY BOARD
**************
3-025-557-01 TERMINAL (–), BATTERY
*************************************************************
* 1-670-177-11 ISS BOARD
**********
< CAPACITOR >
C345 1-162-301-11 CERAMIC 0.0015uF 20% 16V
< SWITCH >
S303 1-771-370-11 SWITCH, SLIDE (ISS)
*************************************************************
* 1-670-174-21 MICROPHONE BOARD
******************
* 3-911-281-01 CUSHION, MIC
< CAPACITOR >
C316 1-162-282-31 CERAMIC 100PF 10% 50V
< DIODE >
D911 8-719-059-97 LED L-34HD (OPR/BATT)
< MICROPHONE >
MIC301 1-542-118-11 MICROPHONE, ELECTRET CONDENSER (MIC)
*************************************************************
AUDIO MICROPHONEBATTERY ISS
