Sony CFS-B5LMK2

– 27 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* 1-670-173-21 SECOND BOARD
**************
< CAPACITOR >
C901 1-101-005-00 CERAMIC 22000PF 50V
C902 1-101-005-00 CERAMIC 22000PF 50V
C903 1-101-005-00 CERAMIC 22000PF 50V
C904 1-101-005-00 CERAMIC 22000PF 50V
C905 1-136-165-00 FILM 0.1uF 5% 50V
C906 1-136-165-00 FILM 0.1uF 5% 50V
< DIODE >
D901 8-719-063-79 DIODE 1N4002B
D902 8-719-063-79 DIODE 1N4002B
D903 8-719-063-79 DIODE 1N4002B
D904 8-719-063-79 DIODE 1N4002B
< RESISTOR >
R919 1-249-421-11 CARBON 2.2K 5% 1/4W
*************************************************************
* 1-670-176-11 SUPPORT BOARD
***************
*************************************************************
* A-3321-335-A TUNER BOARD, COMPLETE
**********************
3-025-547-01 GEAR (VC)
3-025-551-01 CAP (FUNCTION)
7-621-770-67 SCREW +B 2.6X6
< CAPACITOR >
C1 1-162-306-11 CERAMIC 0.01uF 30% 16V
C3 1-162-306-11 CERAMIC 0.01uF 30% 16V
C4 1-104-664-11 ELECT 47uF 20% 10V
C6 1-162-191-31 CERAMIC 2.2PF 10% 50V
C8 1-102-945-00 CERAMIC 8PF 0.5PF 50V
C10 1-162-196-31 CERAMIC 5.6PF 10% 50V
C11 1-162-306-11 CERAMIC 0.01uF 30% 16V
C14 1-162-282-31 CERAMIC 100PF 10% 50V
C15 1-126-963-11 ELECT 4.7uF 20% 50V
C16 1-124-903-11 ELECT 1uF 20% 50V
C17 1-124-907-11 ELECT 10uF 20% 50V
C18 1-124-907-11 ELECT 10uF 20% 50V
C19 1-162-306-11 CERAMIC 0.01uF 30% 16V
C20 1-124-903-11 ELECT 1uF 20% 50V
C21 1-126-961-11 ELECT 2.2uF 20% 50V
C22 1-124-443-00 ELECT 100uF 20% 10V
C23 1-124-902-00 ELECT 0.47uF 20% 50V
C24 1-126-963-11 ELECT 4.7uF 20% 50V
C25 1-126-956-11 ELECT 0.1uF 20% 50V
C26 1-162-203-31 CERAMIC 15PF 5% 50V
C27 1-161-050-00 CERAMIC 0.0082uF 10% 16V
C28 1-161-050-00 CERAMIC 0.0082uF 10% 16V
C29 1-162-282-31 CERAMIC 100PF 10% 50V
C30 1-162-282-31 CERAMIC 100PF 10% 50V
C32 1-162-195-31 CERAMIC 4.7PF 10% 50V
C33 1-162-211-31 CERAMIC 33PF 5% 50V
C35 1-162-282-31 CERAMIC 100PF 10% 50V
C36 1-102-945-00 CERAMIC 8PF 0.5PF 50V
C38 1-162-202-31 CERAMIC 13PF 5% 50V
C39 1-104-729-11 FILM 180PF 5% 100V
C40 1-136-307-11 FILM 0.0043uF 5% 100V
C41 1-136-355-11 FILM 330PF 5% 100V
C42 1-104-731-11 FILM 270PF 5% 100V
C45 1-162-294-31 CERAMIC 0.001uF 10% 50V
C46 1-162-282-31 CERAMIC 100PF 10% 50V
C47 1-162-282-31 CERAMIC 100PF 10% 50V
C48 1-162-294-31 CERAMIC 0.001uF 10% 50V
C50 1-162-282-31 CERAMIC 100PF 10% 50V
C51 1-162-294-31 CERAMIC 0.001uF 10% 50V
C52 1-162-202-31 CERAMIC 13PF 5% 50V
C53 1-162-287-31 CERAMIC 270PF 10% 50V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
< FILTER >
CF1 1-760-738-61 FILTER, CERAMIC
CF2 1-567-670-11 FILTER, CERAMIC
< CONNECTOR >
CN1 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< VARIABLE CAPACITOR >
CT1-4 1-151-710-11 CAP, VAR
CV1-4 1-151-710-11 CAP, VAR (TUNE)
< TRIMMER >
CT5 1-141-486-11 CAP, ADJ 10PF
CT6 1-141-486-11 CAP, ADJ 10PF
CT7 1-141-260-00 CAP, TRIMMER 50PF
CT8 1-141-260-00 CAP, TRIMMER 50PF
< DIODE >
D1 8-719-911-19 DIODE 1SS133T-72
D2 8-719-911-19 DIODE 1SS133T-72
D3 8-719-911-19 DIODE 1SS133T-72
< BPF >
FL1 1-239-831-11 FILTER, BAND PASS
< IC >
IC1 8-752-050-20 IC CXA1538S
TUNER
SUPPORT
SECOND
