Sony CFS-B5LMK2

– 28 –
Sony Corporation
Personal Audio Company
9-924-942-11
99E04075-1
Printed in Japan C1999. 5
Published by General Engineering Dept.
CFS-B5LMK2
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< COIL >
L1 1-416-838-11 COIL, AIR-CORE
L2 1-416-851-11 COIL, AIR-CORE
L3 1-754-001-21 ANTENNA, FERRITE-ROD (MW/LW)
L4 1-406-252-11 COIL (OSC)
L5 1-402-596-11 COIL (ANT)
L6 1-406-280-11 COIL (OSC)
L8 1-406-253-11 COIL (OSC)
L9 1-410-750-41 INDUCTOR 0.47uH
L11 1-414-140-11 INDUCTOR 0.68uH
< TRANSISTOR >
Q1 8-729-036-77 TRANSISTOR KRC107M-AT
Q2 8-729-036-89 TRANSISTOR KTC3198GR-A
< RESISTOR >
R2 1-249-427-11 CARBON 6.8K 5% 1/4W
R3 1-249-421-11 CARBON 2.2K 5% 1/4W
R4 1-247-843-11 CARBON 3.3K 5% 1/4W
R6 1-249-441-11 CARBON 100K 5% 1/4W
R9 1-249-441-11 CARBON 100K 5% 1/4W
R10 1-249-397-11 CARBON 22 5% 1/4W
R11 1-249-427-11 CARBON 6.8K 5% 1/4W
R12 1-249-427-11 CARBON 6.8K 5% 1/4W
R14 1-249-429-11 CARBON 10K 5% 1/4W
R15 1-247-887-00 CARBON 220K 5% 1/4W
R16 1-247-887-00 CARBON 220K 5% 1/4W
R17 1-249-421-11 CARBON 2.2K 5% 1/4W
R30 1-249-417-11 CARBON 1K 5% 1/4W
R31 1-247-854-11 CARBON 9.1K 5% 1/4W
R32 1-249-441-11 CARBON 100K 5% 1/4W
R33 1-249-415-11 CARBON 680 5% 1/4W
< VARIABLE RESISTOR >
RV1 1-228-995-00 RES, ADJ, METAL 22K
RV2 1-225-637-11 RES, VAR, CARBON 100 (FINE TUNE)
< SWITCH >
S1 1-571-147-11 SWITCH, LEVER SLIDE (BAND)
< TRANSFORMER >
T1 1-409-944-11 COIL (DET)
T2 1-406-952-11 TRANSFORMER, IF
*************************************************************
MISCELLANEOUS
***************
! 7 1-769-412-11 CORD, POWER
ANT1 1-501-918-21 ANTENNA, TELESCOPIC
HE101 1-543-876-11 HEAD (ERASE)
HRP101 1-500-454-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
MIC301 1-542-118-11 MICROPHONE, ELECTRET CONDENSER (MIC)
S902 1-762-679-11 SWITCH, LEAF (POWER)
SP901 1-505-955-11 SPEAKER (10cm) (L-CH)
SP902 1-505-955-11 SPEAKER (10cm) (R-CH)
! T901 1-431-917-11 TRANSFORMER, POWER
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-862-811-11 MANUAL, INSTRUCTION (ENGLISH)
3-862-811-31 MANUAL, INSTRUCTION (RUSSIAN)
*************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-648-79 SCREW +BVTP 3X12 TYPE2 N-S
#3 7-685-650-79 SCREW +BVTP 3X16 TYPE2 N-S
#4 7-685-533-14 SCREW +BTP 2.6X6 TYPE2 N-S
#5 7-685-248-19 SCREW +KTP 3X12 TYPE2 N-S
#6 7-682-548-09 SCREW +B 3X8
#7 7-621-770-67 SCREW +B 2.6X6
#8 7-621-770-87 SCREW +B 2.6X5
#9 7-685-851-04 SCREW +BVTT 2X4 (S)
TUNER
The components identified by
mark ! or dotted line with mark.
! are critical for safety.
Replace only with part number
specified.
