2-3. TAPE MECHANISM BLOCK
2-4. “ TUNER BOARD ”, “ AC BOARD ”, “ SECOND BOARD ”
1 BVTP 3 × 10
2 CN301
4
tape mechanism block
3 CN601
2 BVTP 3 × 10
3 CN1
6 CN901
5 CN911
4 TUNER board
TERMINAL,
ANTENNA
9 AC board
0 SECOND board
8 T901
7 BVTP 3 × 10
1 knob (FINE TUNE)
