2-5. “ AUDIO BOARD ”, “ MIC BOARD ”
2-6. DIAL POINTER SETTING
2
knob
(HYPER TREBLE/MEGA BASS)
3
chassis (MD)
9
lever (FUNCTION)
4
BVTP 3x10
6
MIC board
5
SUPPORT board
7
BVTP 3 × 10
8
AUDIO board
1
knob (VOLUME)
3
Set the chassis (TUNE).
4
BVTP 3 × 10
1
Turn the VC drum in the direction
of the allow to its end.
2
Set the pointer to the
center of three vertical lines.
pointer
