90
US
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND
TOTAL HARMONIC
DISTORTION: With 3 ohm loads, both
channels driven, from
200 – 20,000 Hz; rated
55 watts per channel
minimum RMS power,
with no more than 0.7 %
total harmonic distortion
from 250 milli watts to
rated output.
Amplifier section
Surround mode (reference) music power output
Front: 143 W + 143 W
(with SS-TS46)
Center*: 143 W
(with SS-CT46)
Surround*: 143 W + 143
W
(with SS-TS43B)
Subwoofer*: 285 W
(with SS-WS42)
* Depending on the sound field settings and the source,
there may be no sound output.
Inputs (Analog)
VIDEO 1, VIDEO 2 Sensitivity: 450 mV
Impedance: 50 kilohms
Inputs (Digital)
VIDEO 1 (Coaxial) Impedance: 75 ohms
VIDEO 2 (Optical)
Phones Accepts low-and high-
impedance headphones.
Super Audio CD/DVD system
Laser Semiconductor laser
(Super Audio CD/DVD: λ
= 650 nm)
(CD: λ = 790 nm)
Emission duration:
continuous
Signal format system NTSC
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22
kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0
dB)
Tuner section
System PLL quartz-locked digital
synthesizer system
FM tuner section
Tuning range 87.5 – 108.0 MHz
(100 kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range 530 – 1,710 kHz (with the
interval set at 10 kHz)
531 – 1,710 kHz (with the
interval set at 9 kHz)
Antenna (aerial) AM loop antenna (aerial)
Intermediate frequency 450 kHz
Video section
Outputs Video: 1 Vp-p 75 ohms
S video:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
PB/CB, PR/CR: 0.7 Vp-p
75 ohms
HDMI OUT: Type A (19
pin)
Input VIDEO1, VIDEO2: 1 Vp-
p 75 ohms
Speakers
Front
Speaker system Two-way Bass reflex,
magnetically shielded
Speaker unit 70 × 100 mm (2
7
/8 × 4
inches) cone type,
25 mm (1 inch) dia.
balanced dome type
Rated impedance 2.7 ohms
Dimensions (approx.) 265 × 1,108 × 265 mm
(10
1
/2 × 43
5
/8 × 10
1
/2
inches)
(w/h/d)
Mass (approx.) 3.5 kg (7 lb 12 oz)
Center
Speaker system Two-way Bass reflex,
magnetically shielded
Speaker unit 55 × 110 mm (2
1
/4 × 4
3
/8
inches) cone type,
25 mm (1 inch) dia.
balanced dome type
Rated impedance 2.7 ohms
Specifications
