Appendixes
Appendixes A-11
Effect control parameters (continued)
Pattern
No.
Effect type and adjustable parameters
2522 2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (1CHDIR = LEFT/RIGHT/TOP/
BOTTOM/BTM-R/BTM-L/TOP-L/TOP-R)
F3: Direction of picture movement (CH2) (2CHDIR = LEFT/RIGHT/TOP/
BOTTOM/BTM-R/BTM-L/TOP-L/TOP-R)
2523
2524
2ch picture-in-picture (compressed, expanded)
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (1CHDIR = LEFT/RIGHT/TOP/
BOTTOM/HORZ/VERT)
F3: Direction of picture movement (CH2) (2CHDIR = LEFT/RIGHT/TOP/
BOTTOM/HORZ/VERT)
2525
2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (1CHDIR = LEFT/RIGHT/TOP/
BOTTOM)
F3: Direction of picture movement (CH2) (2CHDIR = LEFT/RIGHT/TOP/
BOTTOM)
F4: Direction of effect (CH1) (1chAng = –100 to +100)
F5: Direction of effect (CH2) (2chAng = –100 to +100)
2526 2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (1CHROT = TOP-L1/ TOP-L2/
TOP-R1 /TOP-R2/BTM-R1/ BTM-R2/BTM-L1/ BTM-L2)
F3: Direction of picture movement (CH2) (2CHROT = TOP-L1/ TOP-L2/
TOP-R1 /TOP-R2/BTM-R1/ BTM-R2/BTM-L1/ BTM-L2)
2527 2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (1CHROT = TOP1/ TOP2/
BTM1/ BTM2/LEFT1/LEFT2/RIGHT1/RIGHT2)
F3: Direction of picture movement (CH2) (2CHROT = TOP1/ TOP2/
BTM1/ BTM2/LEFT1/LEFT2/RIGHT1/RIGHT2)
2530
2531
2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (ROTDIR = PLUS/MINUS)
F3: Perspective (Pers = 0 to 100)
2532
2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
F2: Speed of rotation (Rot = –100 to +100)
2521 2ch picture-in-picture (slide)
F1: Delay between channels (Delay = 0 to 100)
F2: Direction of picture movement (CH1) (1CHDIR = LEFT/RIGHT/TOP/
BOTTOM/BTM-R/BTM-L/TOP-L/TOP-R)
F3: Direction of picture movement (CH2) (2CHDIR = LEFT/RIGHT/TOP/
BOTTOM/BTM-R/BTM-L/TOP-L/TOP-R)
(continued)
