Appendixes
A-10 Appendixes
Effect control parameters (continued)
Pattern
No.
Effect type and adjustable parameters
2514
to
2517
2ch picture-in-picture (with perspective, vertical alignment)
F1: Perspective (Pers = 0 to 100)
F2: X-axis size (Size_ X = 0 to 100)
F3: X-axis position (Pos_ X = 0 to 100)
F4: Y-axis size (Size_Y = 0 to 100)
F5: Relative position on Y axis (Gap_Y = 0 to 100)
2518 2ch picture-in-picture (manual)
F1: X-axis rotation (Rot_X = –100 to +100)
F2: Y-axis rotation (Rot_Y = –100 to +100)
F3: Z-axis rotation (Rot_Z = –100 to +100)
F4: Perspective (Pers = 0 to 100)
F5: Form of picture (PTN = RECT/CIRCLE/HEART/DIA/PENTA/HEXA/
5STAR/6STAR)
F6: Direction of X-axis rotation (SYM RX X = ON/OFF)
F7: Direction of Y-axis rotation (SYM RY Y = ON/OFF)
F8: Direction of Z-axis rotation (SYM RZ Z = ON/OFF)
F11: Relative position on X axis (Loc_X2 = –100 to +100)
F12: Relative position on Y axis (Loc _Y2 = –100 to +100)
F13: Relative position on z axis (Loc _Z2 = –100 to +100)
F14: Two-picture combination type (COMBIN = ZLOC/CH1/CH2/MIX)
2519 2ch picture-in-picture (manual)
F1: X-axis rotation (CH1) (Rot_X1 = –100 to +100)
F2: Y-axis rotation (CH1) (Rot_Y1 = –100 to +100)
F3: Z-axis rotation (CH1) (Rot_Z1 = –100 to +100)
F4: Perspective (Pers = 0 to 100)
F5: Form of picture (PTN = RECT/CIRCLE/HEART/DIA)
F6: X-axis rotation (CH2) (Rot_X2 = –100 to +100)
F7: Y-axis rotation (CH2) (Rot_Y2 = –100 to +100)
F8: Z-axis rotation (CH2) (Rot_Z2 = –100 to +100)
F11: X-axis position (CH2) (Loc_X2 = –100 to +100)
F12: Y-axis position (CH2) (Loc_Y2 = –100 to +100)
F13: Z-axis position (CH2) (Loc_Z2 = –100 to +100)
F14: Two-picture combination type (COMBIN = ZLOC/CH1/CH2/MIX)
2520 2ch picture-in-picture
F1: Delay between channels (Delay = 0 to 100)
Effect Control Parameter List
2510
to
2513
2ch picture-in-picture (with perspective, horizontal alignment)
F1: Perspective (Pers = 0 to 100)
F2: Y-axis size (Size_Y = 0 to 100)
F3: Y-axis position (Pos_Y = 0 to 100)
F4: X-axis size (Size_X = 0 to 100)
F5: Relative position on X axis (Gap_X = 0 to 100)
(continued)
