Effect control parameters (continued)
Pattern
No.
Effect type and adjustable parameters
2284
Lens
F1: Amplitude of modulation (Amp = 0 to 100)
F2: Size of lens (Size = 0 to 100)
F3: Form of lens (FORM = FLAT/INNER/OUTER/SPHERE)
F4: Modulation aspect ratio (Aspect = Taller to wider)
F5: Direction of modulation (Angle = 0 to 99)
2400
to
2407
2410
to
2419
Two-picture brick
F1: Depth (Depth = 0 to 100)
F3: Stretching of picture in depth section (Strch = 0 to 100)
F4: Position of picture in depth section (Posi = –100 to +100)
2420
to
2437
Two-picture brick (flip type)
F1: Depth (Depth = 0 to 100)
F2: Form model (FORM = SLAB/DUAL)
F3: Stretching of picture in depth section (Strch = 0 to 100)
F4: Position of picture in depth section (Posi = –100 to +100)
2470
to
2473
Split 3D rotation
F1: Fineness of splitting (Freq = 0 to 100)
2480
to
2489
Masked flip
F1: Mask shape (PATTERN = CIRCLE/HEART/RECT/DIA/HEXA/
5STAR/6STAR/WAVE)
F2: Fineness of splitting (Freq = 0 to 100)
F3: Bias of splitting (Bias = 0 to 100)
2490
to
2499
Masked flip
F1: Mask shape (PATTERN = CHECK1/ CHECK2/ CHECK3/CHECK4/
CHECK5/LINE/RECT1/RECT2)
F2: Mask slant (SLANT = ON/OFF)
2501
to
2507
2ch picture-in-picture
F1: Timing at which picture appears (Delay = 0 to 100)
F2: Picture position (POSITN = HORZ1/HORZ2/HORZ3/VERT1/VERT2/
VERT3/DIAG1/DIAG2)
F3: Picture size (Size = 0 to 100)
F4: Relative position on X axis (Gap_X = 0 to 100)
F5: Relative position on Y axis (Gap_Y = 0 to 100)
2508
2509
2ch picture-in-picture
F2: Picture positon (POSITN = HORZ1/HORZ2/HORZ3/VERT1/VERT2/
VERT3/DIAG1/DIAG2)
F3: Picture size (Size = 0 to 100)
F4: Relative positon on X axis (Gap_X = 0 to 100)
F5: Relative positon on Y axis (Gap_Y = 0 to 100)
(continued)
