Appendixes
A-18 Appendixes
Effect control parameters (continued)
Pattern
No.
Effect type and adjustable parameters
2840 3D cylinder
2841 F1: Amount of X-axis rotation (Rot_X = –100 to +100)
F2: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F3: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F4: Fine adjustment of mapping in X-axis direction (Area_X = 0 to 100)
F5: Fine adjustment of mapping in Y-axis direction (Area_Y = 0 to 100)
F6: Thickness of cylinder (Radius = 0 to 100)
F7: Degree of wave modulation on cylinder sides (Amp = 0 to 100)
F8: Frequency of wave modulation on cylinder sides (Freq = 0 to 100)
F9: Phase of wave modulation on cylinder sides (Phase = 0 to 99)
F10: Position of light source (Light = –100 to +100)
F11: Amount of X-axis auto rotation (Spd_X = –100 to +100)
F12: Amount of Y-axis auto rotation (Spd_Y = –100 to +100)
F13: Amount of Z-axis auto rotation (Spd_Z = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
2842 Sphere, Heart
to F1: Amount of X-axis rotation (Rot_X = –100 to +100)
2845 F2: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F3: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F4: Fine adjustment of mapping in X-axis direction (Area_X = 0 to 100)
F5: Fine adjustment of mapping in Y-axis direction (Area_Y = 0 to 100)
F6: Amount of X-axis auto rotation (Spd_X = –100 to +100)
F7: Amount of Y-axis auto rotation (Spd_Y = –100 to +100)
F8: Amount of Z-axis auto rotation (Spd_Z = –100 to +100)
F10: Position of light source (Light = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
2850 3D wave
to F1: Amount of X-axis rotation (Rot_X = –100 to +100)
2853 F2: Amount of Y-axis rotation (Rot_Y = –100 to +100)
F3: Amount of Z-axis rotation (Rot_Z = –100 to +100)
F4: Perspective (Pers = 0 to 100)
F5: Direction of wave modulation (Angle = 0 to 99)
F6: Amplitude of wave modulation (Amp = 0 to 100)
F7: Frequency of wave modulation (Freq = 0 to 100)
F8: Phase of wave modulation (Phase = 0 to 99)
F9: Speed of auto change in phase of wave modulation (Speed = –100 to
+100)
F10: Position of light source (Light = –100 to +100)
X/Y/Z: Location, enlargement, and reduction of the pattern
Effect Control Parameter List
(continued)
