Parameters for linear user program effects (9000 to 9009 and 9100 to 9109)
User Program Effects
Controls and parameters
Impression of parameter adjustment
Joystick, Loc-X knob
Movement along x-axis
Joystick, Loc-Y knob
Movement along y-axis
Z-knob, Loc-Z knob
Magnification
Rot-X knob
Rotation about the x-axis
Rot-Y knob
Rotation about the y-axis
Rot-Z knob
Rotation about the z-axis
Pers knob
Perspective adjustment
