Appendixes
142 Appendixes
Specifications
Processor adjustment range
Video level ±3 dB/–∞ to 3 dB selectable
Chroma level ±3 dB/–∞ to 3 dB selectable
Setup/Black level
±30 IRE (±210 mV)
Chroma phase ±30˚
Y/C delay ±100 ns
System phase Sync: ±3µs
SC: ±180°
Audio performance
Frequency response
2 ch (48 kHz/16 bit):
20 Hz to 20 kHz +0.5/–1.0 dB
4 ch (32 kHz/12 bit):
20 Hz to 14.5 kHz +0.5/–1.0 dB
Dynamic range 90 dB or more (2CH, 48 kHz)
Distortion 0.05% or less (2CH, 48 kHz)
Input connectors
Digital input
i.LINk 6-pin IEEE1394 connector ×1
SDTI (QSDI) INPUT
BNC type ×1, SDTI (QSDI) format
(270Mbps), SMPTE 305M/322M
SDI INPUT BNC type ×2 (active-through),
SMPTE 259M (DSR-2000A)/ITU-
R BT.656 (DSR-2000AP), SDI
format (270Mbps)
Analog video input
VIDEO IN BNC type ×2 (loop-through),
composite, 1.0 Vp-p, 75 Ω, sync
negative
REF. VIDEO IN BNC type ×2 (loop-through), black
burst, 0.286 Vp-p (DSR-2000A) or
0.3 Vp-p (DSR-2000AP), 75 Ω,
sync negative
S VIDEO IN DIN 4-pin ×1
Y: 1.0 Vp-p, 75 Ω, sync negative
C: 0.286 Vp-p (DSR-2000A) or
0.3 Vp-p (DSR-2000AP), 75 Ω
(burst level)
COMPONENT VIDEO IN Y/R–Y/B–Y
BNC type ×3, component video
Y: 1.0 Vp-p, 75 Ω, sync negative
R–Y: 0.7 Vp-p, 75 Ω (75% color
bars for DSR -2000A or 100%
color bars for DSR-2000AP)
B–Y: 0.7Vp-p, 75 Ω (75% color
bars for DSR -2000A or 100%
color bars for DSR-2000AP)
Analog audio input
AUDIO IN XLR 3-pin (female) ×4,
–6/0/+4 dBu, 600 Ω ON/OFF/–60
dBu, high impedance, balanced
Digital audio input
DIGITAL AUDIO (AES/EBU) IN CH-1/2, CH-3/4
BNC×2, complying with AES-3id-
1995
Timecode input
TIME CODE IN BNC type ×1, SMPTE (DSR-
2000A)/EBU (DSR-2000AP)
0.5 to 18 Vp-p, 3.3 kΩ, unbalanced
Output connectors
Digital output
i.LINK 6-pin IEEE1394 connector ×1
SDTI (QSDI) OUTPUT
BNC type ×1, SDTI (QSDI) format
(270Mbps), SMPTE 305M/322M
SDI OUTPUT 1, 2, 3 (SUPER)
BNC type ×3, SMPTE 259M
(DSR-2000A)/ITU-R BT.656
(DSR-2000AP), SDI format
(270Mbps)
Analog video output
VIDEO OUT 1, 2, 3 (SUPER)
BNC type ×3, composite, 1.0 Vp-p,
75 Ω, sync negative
REF. VIDEO OUT
BNC type ×1, composite sync,
0.286 Vp-p (DSR-2000A) or 0.3
Vp-p (DSR-2000AP), 75 Ω, sync
negative (with burst)
