S VIDEO OUT DIN 4-pin ×1
Y: 1.0 Vp-p, 75 Ω, sync negative
C: 0.286 Vp-p (DSR-2000A) or
0.3 Vp-p (DSR-2000AP), 75 Ω
(burst level)
COMPONENT VIDEO OUT Y/R–Y/B–Y
BNC type ×3, component video
Y: 1.0 Vp-p, 75 Ω, sync negative
R–Y: 0.7 Vp-p, 75 Ω (75% color
bars for DSR-2000A or 100%
color bars for DSR-2000AP)
B–Y: 0.7Vp-p, 75 Ω (75% color
bars for DSR-2000A or 100%
color bars for DSR-2000AP)
Analog audio output
AUDIO OUT XLR 3-pin (male) ×4, +4/0/–6 dBu
(selectable by menu setting),
600 Ω loaded, low impedance,
balanced
MONITOR AUDIO
Phono jack ×1, –11 dBu, 47 kΩ
load, unbalanced
Digital audio output
DIGITAL AUDIO (AES/EBU) OUT CH-1/2, CH-3/4
BNC×2, complying with AES-3id-
1995
Headphone output
HEADPHONES Stereo phone jack ×1, –∞ to
–13 dBu, 8 Ω, unbalanced
Timecode output
TIME CODE OUT
BNC type ×1, SMPTE (DSR-
2000A)/EBU (DSR-2000AP)
2.2 Vp-p±3.0 dB, 600 Ω,
unbalanced, (when 75 Ω
terminated)
Control connectors
VIDEO CONTROL
D-sub 15-pin, male, for connection
of optional UVR-60/60P or BVR-
50/50P
CONTROL PANEL
D-sub 15-pin, female
REMOTE-IN D-sub 9-pin, female, for connection
of another DSR-2000A/2000AP
unit or other editing controller,
complying with RS-422A
REMOTE-OUT D-sub 9-pin, female, for loop-
through output of signals from the
REMOTE-IN connector
Accessories supplied
AC power cord (1)
Operating Instructions
English version (1)
CD-ROM manual (1)
Accessories not supplied
RCC-5G 9-pin Remote Control Cable (5 m (16 ft)
long)
RMM-131/1 Rack Mount Kit
PDV-64*/94*/124*/184*/34* Digital Video Cassette
(standard size)
a)
PDVM-12*/22*/32*/40* Digital Video Cassette (mini-
size)
a)
a) The * in each model name is actually “ME”
(indicating that a cassette memory is contained), or
“N” (indicating that no cassette memory is
contained).
DV12CL Cleaning Cassette (standard size)
DVM12CL Cleaning Cassette (mini-size)
Design and specifications are subject to change
without notice.
