Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
70
DVP-S9
R406 1-216-846-11 METAL CHIP 120K 5% 1/16W
R407 1-216-846-11 METAL CHIP 120K 5% 1/16W
R408 1-216-847-11 METAL CHIP 150K 5% 1/16W
R409 1-216-847-11 METAL CHIP 150K 5% 1/16W
R410 1-216-842-11 METAL CHIP 56K 5% 1/16W
R411 1-216-842-11 METAL CHIP 56K 5% 1/16W
R412 1-216-850-11 METAL CHIP 270K 5% 1/16W
R413 1-216-833-11 METAL CHIP 10K 5% 1/16W
R414 1-216-853-11 METAL CHIP 470K 5% 1/16W
R415 1-216-846-11 METAL CHIP 120K 5% 1/16W
R416 1-216-855-11 METAL CHIP 680K 5% 1/16W
R417 1-216-833-11 METAL CHIP 10K 5% 1/16W
R418 1-216-839-11 METAL CHIP 33K 5% 1/16W
R419 1-216-839-11 METAL CHIP 33K 5% 1/16W
R420 1-216-853-11 METAL CHIP 470K 5% 1/16W
R421 1-216-839-11 METAL CHIP 33K 5% 1/16W
R422 1-216-839-11 METAL CHIP 33K 5% 1/16W
R423 1-216-839-11 METAL CHIP 33K 5% 1/16W
R424 1-216-839-11 METAL CHIP 33K 5% 1/16W
R425 1-216-849-11 METAL CHIP 220K 5% 1/16W
R426 1-216-853-11 METAL CHIP 470K 5% 1/16W
R427 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R428 1-216-839-11 METAL CHIP 33K 5% 1/16W
R429 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R430 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R431 1-218-889-11 METAL CHIP 56K 0.5% 1/10W
R432 1-216-833-11 METAL CHIP 10K 5% 1/16W
R433 1-216-833-11 METAL CHIP 10K 5% 1/16W
R434 1-216-815-11 METAL CHIP 330 5% 1/16W
R435 1-216-833-11 METAL CHIP 10K 5% 1/16W
R439 1-216-864-11 METAL CHIP 0 5% 1/16W
R507 1-216-809-11 METAL CHIP 100 5% 1/16W
R508 1-216-864-11 METAL CHIP 0 5% 1/16W
R509 1-216-864-11 METAL CHIP 0 5% 1/16W
R510 1-216-833-11 METAL CHIP 10K 5% 1/16W
R511 1-216-813-11 METAL CHIP 220 5% 1/16W
R512 1-216-813-11 METAL CHIP 220 5% 1/16W
R513 1-216-813-11 METAL CHIP 220 5% 1/16W
R514 1-216-813-11 METAL CHIP 220 5% 1/16W
R515 1-216-813-11 METAL CHIP 220 5% 1/16W
R516 1-216-813-11 METAL CHIP 220 5% 1/16W
R517 1-216-833-11 METAL CHIP 10K 5% 1/16W
R518 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R521 1-216-864-11 METAL CHIP 0 5% 1/16W
R522 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R524 1-216-833-11 METAL CHIP 10K 5% 1/16W
R525 1-216-833-11 METAL CHIP 10K 5% 1/16W
R532 1-216-833-11 METAL CHIP 10K 5% 1/16W
R533 1-216-797-11 METAL CHIP 10 5% 1/16W
R554 1-216-797-11 METAL CHIP 10 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R711 1-218-289-11 RES-CHIP 510 5% 1/16W
R712 1-218-289-11 RES-CHIP 510 5% 1/16W
R713 1-218-289-11 RES-CHIP 510 5% 1/16W
R717 1-218-285-11 RES-CHIP 75 5% 1/16W
R718 1-218-285-11 RES-CHIP 75 5% 1/16W
R719 1-218-285-11 RES-CHIP 75 5% 1/16W
R724 1-216-833-11 METAL CHIP 10K 5% 1/16W
R725 1-216-833-11 METAL CHIP 10K 5% 1/16W
R737 1-216-864-11 METAL CHIP 0 5% 1/16W
R738 1-216-864-11 METAL CHIP 0 5% 1/16W
R739 1-216-864-11 METAL CHIP 0 5% 1/16W
R740 1-216-864-11 METAL CHIP 0 5% 1/16W
< VARIABLE RESISTOR >
RV501 1-223-583-11 RES, ADJ, CARBON 1K
< VIBRATOR >
X101 1-795-174-11 VIBRATOR, CERAMIC (16.5MHz)
X102 1-767-519-11 VIBRATOR, CRYSTAL (27MHz)
**************************************************************
1-678-461-11 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30% 16V
**************************************************************
1-682-812-11 PANEL BOARD
************
< DIODE >
D701 8-719-057-97 LED SEL5923A-TP15 (X )
D702 8-719-058-03 LED SEL5423E-TP15 (N)
D703 8-719-057-97 LED SEL5923A-TP15 (3 (DISC 3))
D704 8-719-057-97 LED SEL5923A-TP15 (2 (DISC 2))
D705 8-719-057-97 LED SEL5923A-TP15 (1 (DISC 1))
< RESISTOR >
R711 1-249-411-11 CARBON 330 5% 1/4W
R712 1-249-413-11 CARBON 470 5% 1/4W
R713 1-249-414-11 CARBON 560 5% 1/4W
R714 1-249-415-11 CARBON 680 5% 1/4W
R715 1-249-417-11 CARBON 1K 5% 1/4W
R716 1-249-418-11 CARBON 1.2K 5% 1/4W
R717 1-249-420-11 CARBON 1.8K 5% 1/4W
R718 1-249-422-11 CARBON 2.7K 5% 1/4W
R719 1-247-843-11 CARBON 3.3K 5% 1/4W
< SWITCH >
S711 1-771-410-21 SWITCH, TACTILE (m)
S712 1-771-410-21 SWITCH, TACTILE (M)
S713 1-771-410-21 SWITCH, TACTILE (>)
S714 1-771-410-21 SWITCH, TACTILE (.)
S715 1-771-410-21 SWITCH, TACTILE (x)
S716 1-771-410-21 SWITCH, TACTILE (X)
S717 1-771-410-21 SWITCH, TACTILE (N)
S718 1-771-410-21 SWITCH, TACTILE (RETURN)
S719 1-771-410-21 SWITCH, TACTILE (PREV)
S720 1-771-410-21 SWITCH, TACTILE (NEXT)
**************************************************************
MB MOTOR PANEL
