Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
71
DVP-S9
A-4727-278-A RF BOARD, COMPLETE
********************
< CAPACITOR >
C001 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C002 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C005 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C006 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C007 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C008 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C009 1-124-779-00 ELECT CHIP 10uF 20% 16V
C015 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C016 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C017 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C018 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C019 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C021 1-124-779-00 ELECT CHIP 10uF 20% 16V
C022 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C023 1-126-206-11 ELECT CHIP 100uF 20% 6.3V
C024 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C026 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C027 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C028 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C031 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C033 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C034 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C035 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C036 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C038 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C039 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C040 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C043 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C044 1-124-779-00 ELECT CHIP 10uF 20% 16V
C046 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C048 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN001 1-766-835-21 CONNECTOR, FFC/FPC (ZIF) 26P
CN002 1-784-875-21 CONNECTOR, FFC (LIF (NON-ZIF)) 25P
< DIODE >
D001 8-719-988-61 DIODE 1SS355TE-17
D004 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC001 8-759-828-02 IC SP3728AC
< COIL >
L001 1-412-031-11 INDUCTOR CHIP 47uH
L002 1-412-031-11 INDUCTOR CHIP 47uH
< TRANSISTOR >
Q001 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
Q002 8-729-903-46 TRANSISTOR 2SB1132-T100-QR
< RESISTOR >
R002 1-216-809-11 METAL CHIP 100 5% 1/16W
R003 1-216-809-11 METAL CHIP 100 5% 1/16W
R005 1-216-845-11 METAL CHIP 100K 5% 1/16W
R006 1-216-838-11 METAL CHIP 27K 5% 1/16W
R007 1-216-803-11 METAL CHIP 33 5% 1/16W
R008 1-216-803-11 METAL CHIP 33 5% 1/16W
R009 1-216-821-11 METAL CHIP 1K 5% 1/16W
R010 1-216-841-11 METAL CHIP 47K 5% 1/16W
R011 1-216-809-11 METAL CHIP 100 5% 1/16W
R020 1-216-803-11 METAL CHIP 33 5% 1/16W
R023 1-216-803-11 METAL CHIP 33 5% 1/16W
R025 1-216-841-11 METAL CHIP 47K 5% 1/16W
R029 1-216-809-11 METAL CHIP 100 5% 1/16W
R037 1-216-834-11 METAL CHIP 12K 5% 1/16W
R038 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R045 1-216-809-11 METAL CHIP 100 5% 1/16W
**************************************************************
1-682-814-11 SUB PANEL BOARD
*****************
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-413-11 CARBON 470 5% 1/4W
R703 1-249-414-11 CARBON 560 5% 1/4W
R704 1-249-415-11 CARBON 680 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
R706 1-249-418-11 CARBON 1.2K 5% 1/4W
R707 1-249-420-11 CARBON 1.8K 5% 1/4W
< SWITCH >
S701 1-771-410-21 SWITCH, TACTILE (DISC 3)
S702 1-771-410-21 SWITCH, TACTILE (DISC 2)
S703 1-771-410-21 SWITCH, TACTILE (DISC 1)
S704 1-771-410-21 SWITCH, TACTILE (Z (DISC 1))
S705 1-771-410-21 SWITCH, TACTILE (Z (DISC 2))
S706 1-771-410-21 SWITCH, TACTILE (Z (DISC 3))
S707 1-771-410-21 SWITCH, TACTILE (REPEAT)
S708 1-771-410-21 SWITCH, TACTILE (PLAY MODE)
**************************************************************
1-678-457-11 TRAY SENSOR BOARD
*******************
< CAPACITOR >
C731 1-164-159-11 CERAMIC 0.1uF 50V
< PHOTO SENSOR >
IC731 8-749-016-76 PHOTO SENSOR RPI-321
(SUB TRAY 1 HEIGHT SENSOR)
IC732 8-749-016-76 PHOTO SENSOR RPI-321
(SUB TRAY 2 HEIGHT SENSOR)
IC733 8-749-016-76 PHOTO SENSOR RPI-321
(SUB TRAY 3 HEIGHT SENSOR)
< RESISTOR >
R731 1-247-876-11 CARBON 75K 5% 1/4W
R732 1-249-408-11 CARBON 180 5% 1/4W
RF SUB PANEL TRAY SENSOR
Ver 1.2
