Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
72
DVP-S9
R733 1-247-876-11 CARBON 75K 5% 1/4W
R734 1-249-408-11 CARBON 180 5% 1/4W
R735 1-247-876-11 CARBON 75K 5% 1/4W
R736 1-249-408-11 CARBON 180 5% 1/4W
**************************************************************
A-4727-238-A VIDEO BOARD, COMPLETE
**********************
< CAPACITOR >
C203 1-164-159-11 CERAMIC 0.1uF 50V
C204 1-126-934-11 ELECT 220uF 20% 10V
C206 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN201 1-779-276-11 CONNECTOR, FFC (LIF (NON-ZIF)) 8P
CN202 1-568-951-11 PIN, CONNECTOR 2P
< FERRITE BEAD >
FB201 1-412-473-21 FERRITE BEAD
FB202 1-412-473-21 FERRITE BEAD
FB203 1-412-473-21 FERRITE BEAD
FB204 1-412-473-21 FERRITE BEAD
< IC >
IC201 8-749-923-04 IC TOTX178A (OPTICAL OUT TO ST-S9)
< JACK >
J201 1-537-943-11 CONNECTOR (DIN) 1P (S VIDEO OUT)
J202 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L201 1-410-525-11 INDUCTOR 220uH
**************************************************************
MISCELLANEOUS
**************
0 1 1-476-027-11 POWER BLOCK (AUS, EA, SP, TH)
0 1 1-476-028-11 POWER BLOCK (AEP, KR, UK)
0 1 1-476-029-11 POWER BLOCK (E, MX)
0 5 1-823-394-11 CORD, POWER (E, MX)
0 5 1-823-396-11 CORD, POWER (AEP, AUS, EA, SP, TH, UK)
0 5 1-823-399-11 CORD, POWER (KR)
101 1-823-609-11 WIRE (FLAT TYPE) (25 CORE)
104 1-823-608-11 WIRE (FLAT TYPE) (10 CORE)
107 1-823-607-11 WIRE (FLAT TYPE) (8 CORE)
108 1-757-633-11 CORD (WITH CONNECTOR) 17P
702 1-823-611-11 WIRE (FLAT TYPE) (9 CORE)
703 1-823-610-11 WIRE (FLAT TYPE) (26 CORE)
0 706 8-820-144-06 OPTICAL PICK-UP KHM-240AAA/J1RP
(TYPE A)
0 706 A-6062-709-A SERVICE ASSY, KHM-270AAA (TYPE B)
0 F1 1-532-388-31 MINIATURE FUSE-LINKS, TIME-LAG FUSE
(T2AL/250V)
M721 X-4952-971-2 MOTOR ASSY (LOADING)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
TRAY SENSOR VIDEO
