Basic Functions
FCB-EV7520A(GB) D-023-100-11(1)
23
Eclipse
When designing the housing, refer to the dimensional
allowance as shown in the figure below.
unit: mm (inches)
Spectral Sensitivity
Characteristics
0.0
0.2
0.4
0.6
0.8
1.0
400 500 600 700 800 900 1000
Relative response [a.u.]
Wavelength [nm]
Red Green Blue
Use the graph as a reference value. (We can not
guarantee these values.)
This data is measured when the IR cut filter is removed
and the characteristics of the lens and optical source
characteristics are ignored.
