Sony FCB-EV7520A - LVDS Receiver IC (E.g., THC63 LVD1024, BU90 R102)

Specifications
FCB-EV7520A(GB) D-023-100-11(1)
64
Pin No. Description Signal
1 PGND_1
2 PVCC_2
3 RESERVED
4 PDWN
5 MODE0
6 MODE1
7 DK
8 R/F
9 OE
10 MODE2
11 MAP
12 VCC_12
13 GND_13
14 R20
15 R21
16 R22
17 R23
18 R24
19 R25
20 R26
21 VCC_21
22 GND_22
23 R27
24 R28
25 R29
26 G20
27 G21
28 VCC_28
29 VCC_29
30 GND_30
31 G22
32 G23
33 G24
34 G25
35 G26
36 G27
37 G28
38 VCC_38
39 GND_39
40 G29
41 B20
42 B21
43 B22
44 B23
45 B24
46 VCC_46
47 GND_47
48 B25
49 B26
50 B27
Pin No. Description Signal
51 B28
52 B29
53 VCC_53
54 GND_54
55 CONT21
56 CONT22
57 VCC_57
58 GND_58
59 GND_59
60 CLKOUT CLK
61 CVCC
62 CGND
63 R10
64 R11
65 R12 Y0
66 R13 Y1
67 R14 Y2
68 R15 Y3
69 R16 Y4
70 VCC_70
71 GND_71
72 R17 Y5
73 R18 C7
74 R19 C6
75 G10
76 G11
77 G12 Y6
78 G13 Y7
79 G14 HSYNC
80 VCC_80
81 GND_81
82 G15 VSYNC
83 G16
84 G17
85 G18
86 G19
87 B10
88 VCC_88
89 GND_89
90 B11
91 B12
92 B13
93 B14 C0
94 B15 C1
95 B16 C2
96 B17 C3
97 VCC_97
98 GND_98
99 B18
100 B19
LVDS receiver IC (e.g., THC63LVD1024, BU90R102)
Pin assigment Double mode LVDS input - CMOS output
Pin No. Description Signal
101 HSYNC C4
102 VSYNC C5
103 DE DE
104 CONT11
105 CONT12
106 VCC_106
107 PVCC_107
108 PGND_108
109 LGND_109
110 RA1− TXOUT0−
111 RA1+ TXOUT0+
112 RB1− TXOUT1−
113 RB1+ TXOUT1+
114 LVCC_114
115 LGND_115
116 RC1− TXOUT2−
117 RC1+ TXOUT2+
118 RCLK− TXCLKOUT−
119 RCLK+ TXCLKOUT+
120 LVCC_120
121 LGND_121
122 RD1− TXOUT3−
123 RD1+ TXOUT3+
124 RE1−
125 RE1+
126 LVCC_126
127 LGND_127
128 RA2− TXOUT4−
129 RA2+ TXOUT4+
130 RB2− TXOUT5−
131 RB2+ TXOUT5+
132 LVCC_132
133 LGND_133
134 RC2− TXOUT6−
135 RC2+ TXOUT6+
136 LGND_136
137 LGND_137
138 LVCC_138
139 LVCC_139
140 RD2− TXOUT7−
141 RD2+ TXOUT7+
142 RE2−
143 RE2+
144 LGND_144
