Sony FCB-EV7520A - Register Setting Table

Command List
FCB-EV7520A(GB) D-023-100-11(1)
54
Register Setting
Register
name
Register
No.
Setting value Setting value
reflection
timing*
VISCA
Baud Rate
00 00
(Iinitial Setting)
9600 bps Reflected after
camera reset
01 19200 bps
02 38400 bps
03 115200 bps
Monitoring
Mode
72 01
(Iinitial Setting)
1080i/59.94 Reflected after
camera reset
02 1080i/60
04 1080i/50
06 1080p/29.97
07 1080p/30
08 1080p/25
09 720p/59.94
0A 720p/60
0B Reserved
0C 720p/50
0D Reserved
0E 720p/29.97
0F 720p/30
10 Reserved
11 720p/25
12 Reserved
13 1080p/59.94
14 1080p/50
15 1080p/60
LVDS
Mode
74 00
(Iinitial Setting)
Single output Reflected after
camera reset
01 Double
output
Zoom
Limit
50 00-FF
(Iinitial Setting: 00)
Wide Limit
(0: Disabled)
Reflected after
camera reset
51 00-FF
(Iinitial Setting: 00)
Tele Limit
(0: Disabled)
D-Zoom
Max
52 00-EB
(Iinitial Setting: EB)
Max. digital
zoom ratio =
256 ÷
(256-Value)
Reflected after
camera reset
“StableZoom” 53 00
(Iinitial Setting: 00)
Off Immediate
reflection
01 On
* Timing to reflect register setting value changes
• Reflect after camera reset: After the setting value is changed, changes are
reflected following camera reset by “Camera reset command” or
“Camera power supply turned OFF and then ON again”.
• Reflect immediately: Changes are reflected immediately after the setting
value is changed.
Register
name
Register
No.
Setting value Setting value
reflection
timing*
FocusTrace
@ZoomDirect
54 00 Off Reflected after
camera reset
01
(Iinitial Setting: 01)
On
FocusOffset
@DomeCover
55 00-FF
(Iinitial Setting: 00)
00: None to
FF: Max.
Reflected after
camera reset
AE
Parameter
Change
During VE
On, Defog
On
58 00 OFF Immediate
reflection
01
(Iinitial Setting)
ON
Auto Slow
Shutter
Limit
59 01 1/30 Immediate
reflection
02 1/15
03 1/8
04
(Iinitial Setting)
1/4
05 1/2
06 1/1
Extended
Normal
Shutter
5A 00
(Iinitial Setting)
OFF Immediate
reflection
01 Allowed up
to 1/30
02 Allowed up
to 1/15
03 Allowed up
to 1/8
04 Allowed up
to 1/4
05 Allowed up
to 1/2
06 Allowed up
to 1/1
Defog
Limit
5B 00-FF
(Iinitial Setting: FF)
Defog level
Low Limit
Immediate
reflection
5C 00-FF
(Iinitial Setting: FF)
Defog level
Mid Limit
5D 00-FF
(Iinitial Setting: FF)
Defog level
High Limit
Extended
Mode
5F 00
(Iinitial Setting)
OFF Immediate
reflection
bit: 0 Exposure compensation
Extended 256 levels On/Off
bit: 1 Aperture Extended 256
levels On/Off
bit: 2 Color Gain/Hue
Extended 256 levels On/Off
bit: 3 Auto ICR Off
 On
setting enable On/Off
* For all of bit, 1 is to activate, 0
is Off
