Locations of Controls
FCB-EV7520A(GB) D-023-100-11(1)
5
Locations of Controls
Lens
Digital output connector
Maintenance connector
* Do not connect here, this is for maintenance purpose.
Tripod screw hole
When a tripod is used, please use 7 mm (
9
/
32
in.) or less screw to attach it to the camera.
Also, please be sure to attach the tripod securely.
Front
Back
Bottom
