Sony FCB-EV7520A - Page 43

Command List
FCB-EV7520A(GB) D-023-100-11(1)
43
Inquiry Command List (3/4)
Inquiry Command Command Packet Inquiry Packet Comments
CAM_DisplayModeInq 8x 09 04 15 FF
(8x 09 06 06 FF)
y0 50 02 FF On
y0 50 03 FF
Off
CAM_StabilizerModeInq 8x 09 04 34 FF y0 05 02 FF On
y0 05 03 FF
Off
y0 05 00 FF
Hold
CAM_MuteModeInq 8x 09 04 75 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_PrivacyDisplayInq 8x 09 04 77 FF y0 50 pp pp pp pp FF pp pp pp pp: Mask Display (0: Off, 1: On)
CAM_PrivacyPanTiltInq 8x 09 04 79 FF y0 50 0p 0p 0p 0q 0q 0q FF ppp: Pan
qqq: Tilt
CAM_PrivacyPTZInq 8x 09 04 7B mm FF y0 50 0p 0p 0p 0q 0q 0q 0r 0r 0r 0r
FF
mm: Mask Settings
ppp: Pan
qqq: Tilt
rrrr: Zoom
CAM_PrivacyMonitorInq 8x 09 04 6F FF y0 50 pp pp pp pp FF pp pp pp pp: Mask is displayed now.
CAM_IDInq 8x 09 04 22 FF y0 50 0p 0q 0r 0s FF pqrs: Camera ID
CAM_VersionInq 8x 09 00 02 FF y0 50 00 20
mn pq rs tu vw FF
mnpq: Model Code (06xx)
rstu: ROM version
vw: Socket Number (=02)
CAM_MDModeInq 8x 09 04 1B FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_MDFunctionInq 8x 09 04 1C FF y0 50 0m 0n 0p 0q 0r 0s FF m: Display mode
n: Detection Frame Set (00h to 0Fh)
pq: Threshold Level (00h to FFh)
rs: Interval Time set (00h to FFh)
CAM_MDWindowInq 8x 09 04 1D 0m FF y0 50 pp 0q rr 0s FF m: Select Detection Frame (0, 1, 2, 3)
pp: Start Horizontal Position (00h to 10h)
q: Start Vertical Position (00h to 0Eh)
rr: Stop Horizontal Position (01h to 11h)
s: Stop Vertical Position (01h to 0Fh)
CAM_ContinuousZoomPos
ReplyModeInq
8x 09 04 69 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_ZoomPosReply
IntervalTimeInq
8x 09 04 6A FF y0 50 00 00 0p 0p FF pp: Interval Time
CAM_Continuous
FocusPosReplyModeInq
8x 09 04 16 FF y0 50 02 FF On
y0 50 03 FF
Off
CAM_FocusReply
IntervalTimeInq
8x 09 04 1A FF y0 50 00 00 0p 0p FF pp: Interval Time
CAM_RegisterValueInq 8x 09 04 24 mm FF y0 50 0p 0p FF mm: Register No. (=00h to 7Fh)
pp: Register Value (=00h to FFh)
CAM_ChromaSuppressInq 8x 09 04 5F FF y0 50 pp FF pp: Chroma Suppress setting level
CAM_ColorGainInq 8x 09 04 49 FF y0 50 00 00 00 0p FF p: Color Gain Setting 0h to Eh
CAM_ColorHueInq 8x 09 04 4F FF y0 50 00 00 00 0p FF p: Color Hue Setting 0h to Eh
CAM_TempInq 8x 09 04 68 FF Y0 50 00 00 0p 0q FF pq: Lens Temperature
CAM_GammaOffsetInq 8x 09 04 1E FF y0 50 00 00 00 0s 0t 0u FF s: Polarity offset (0 is plus, 1 is minus)
tu: Offset s=0 (00h to 40h)
Offset s=1 (00h to 40h)
CAM_ContrastAdjLevelInq 8x 09 05 5D FF y0 50 0p 0q FF pq: Contrast adjustment value
(low) 00h to 80h (no adjustment) to FFh (high)
CAM_ExExpCompPosInq 8x 09 04 1F 4E FF y0 50 00 00 0p 0q FF pq: Exposure compensation level pq = 00h to FFh
