FST-GTK11iP/GTK33iP/RDH-GTK11iP/GTK33iP
11
PANEL BOARD, IP BOARD, USB BOARD SERVICE POSITION
LED BOARD SERVICE POSITION
MAIN board
USB board
IP board
PANEL board
– Rear left view –
LED board
LED board
–
Front left view –
