Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
FST-GTK11iP/GTK33iP/RDH-GTK11iP/GTK33iP
7575
0 R1010 1-216-793-91 METAL CHIP 4.7 5% 1/10W
0 R1011 1-216-864-91 SHORT CHIP 0
< TRANSFORMER >
0 T901 1-445-950-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-811-315-31 POWER THERMISTOR
< VARISTOR >
0 VDR901 1-811-165-31 VARISTOR (TVR10471-D)
************************************************************
GTK33-SMPS BOARD (GTK33iP)
****************
7-685-647-71 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C902 1-112-869-51 CERAMIC 470PF 10% 250V
0 C903 1-112-869-51 CERAMIC 470PF 10% 250V
0 C905 1-114-594-21 FILM 0.22uF 10% 250V
0 C907 1-116-397-21 FILM 0.33uF 10% 250V
0 C909 1-112-870-51 CERAMIC 0.001uF 20% 250V
0 C911 1-113-925-51 CERAMIC 0.01uF 20% 250V
0 C912 1-113-925-51 CERAMIC 0.01uF 20% 250V
0 C914 1-114-347-22 ELECT (BLOCK) 330uF 20% 450V
0 C930 1-164-814-91 CERAMIC CHIP 470PF 2% 50V
0 C931 1-117-815-11 FILM 1000PF 3% 1.5KV
0 C932 1-114-160-91 CERAMIC CHIP 1uF 10% 100V
0 C933 1-164-230-91 CERAMIC CHIP 220PF 5% 50V
0 C934 1-107-904-91 ELECT 3.3uF 20% 50V
0 C935 1-164-227-91 CERAMIC CHIP 0.022uF 10% 25V
0 C936 1-164-814-91 CERAMIC CHIP 470PF 2% 50V
0 C937 1-128-562-91 ELECT 47uF 20% 100V
0 C938 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
0 C939 1-116-393-11 FILM 0.0033uF 5% 400V
C943 1-128-963-11 ELECT 1000uF 20% 50V
C944 1-128-963-11 ELECT 1000uF 20% 50V
C946 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C947 1-165-895-91 CERAMIC CHIP 0.1uF 10% 50V
C950 1-126-965-91 ELECT 22uF 20% 50V
0 C966 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
0 C967 1-117-220-81 CERAMIC 150PF 5% 2KV
0 C968 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
0 C969 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
0 C970 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
0 C971 1-107-930-91 ELECT 22uF 20% 100V
0 C972 1-164-230-91 CERAMIC CHIP 220PF 5% 50V
0 C975 1-112-470-11 CERAMIC 470PF 10% 500V
C977 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C982 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C983 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C986 1-112-232-11 ELECT 2700uF 20% 16V
C989 1-126-965-91 ELECT 22uF 20% 50V
< CONNECTOR >
0 CN901 1-564-321-11 PIN, CONNECTOR (3.96 mm PITCH) 2P
< DIODE >
0 D901 8-719-510-63 DIODE D4SB60L-F
0 D930 6-503-040-01 DIODE DZ2J300M0L
0 D931 6-502-961-01 DIODE DA2J10100L
0 D932 6-503-040-01 DIODE DZ2J300M0L
0 D934 6-502-976-01 DIODE DZ2J150M0L
0 D935 6-502-961-01 DIODE DA2J10100L
0 D937 6-502-967-01 DIODE DZ2J06200L
0 D938 6-502-961-01 DIODE DA2J10100L
0 D939 6-502-961-01 DIODE DA2J10100L
0 D940 6-503-731-01 DIODE SARS10
0 D941 8-719-063-74 DIODE D1NL20U-TR2
D943 6-501-849-01 DIODE FMX-22SL
D944 6-503-032-01 DIODE DZ2J180M0L
0 D966 6-503-044-01 DIODE DZ2J360M0L
0 D967 8-719-063-74 DIODE D1NL20U-TR2
0 D968 6-503-036-01 DIODE DZ2J220M0L
0 D969 6-503-032-01 DIODE DZ2J180M0L
0 D970
8-719-063-74 DIODE D1NL20U-TR2
0 D972 6-503-036-01 DIODE DZ2J220M0L
0 D975 6-502-234-01 DIODE EG01C LF-F7
D981 6-503-458-01 DIODE RK49LF-T1
0 D982 6-503-040-01 DIODE DZ2J300M0L
0 D984 8-719-083-71 DIODE UDZSUSTE-1730B
D985 6-502-979-01 DIODE DA4J104K0L
< FUSE >
0 F901 1-523-067-51 FUSE (5 A/250 V)
< IC >
0 IC931 6-716-854-01 IC STR-X6768N
IC932 6-711-947-01 IC MM1431CURE
0 IC965 6-714-671-01 IC STR-Y6763
IC966 6-711-947-01 IC MM1431CURE
< COIL >
0 L901 1-460-371-11 COIL, LINE FILTER
0 L902 1-460-371-11 COIL, LINE FILTER
L930 1-457-878-65 CHOKE COIL 2.2uH
L969 1-457-578-11 CHOKE COIL 10uH
< PHOTO COUPLER >
0 PH930 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PH931 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PH965 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
0 Q930 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
0 Q932 6-552-746-01 TRANSISTOR DSA700300L
Q933 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q934 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q935 8-729-038-42 TRANSISTOR RT1N441M-TP-1
0 Q965 6-552-502-01 TRANSISTOR DSC7003R0L
< RESISTOR >
0 R901 1-240-938-51 METAL 1.5M 5% 0.5W F
Note 1: When the T901 and VDR901 on the GTK11-SMPS board are
replaced, spread the bond referring to “BOND FIXATION OF
ELECTRIC PARTS” on servicing notes (page 6).
Note 2: When the C905, C911, C912, C914, C943, C944, C986, L901 and L902 on the GTK33-SMPS board are re-
placed, spread the bond referring to “BOND FIXATION OF ELECTRIC PARTS” on servicing notes (page 6).
GTK11-SMPS GTK33-SMPS
