Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
100
R249 1-216-809-11 METAL CHIP 100 5% 1/10W
R250 1-216-809-11 METAL CHIP 100 5% 1/10W
R251 1-216-813-11 METAL CHIP 220 5% 1/10W
R252 1-216-809-11 METAL CHIP 100 5% 1/10W
R254 1-216-809-11 METAL CHIP 100 5% 1/10W
R255 1-216-809-11 METAL CHIP 100 5% 1/10W
R257 1-216-813-11 METAL CHIP 220 5% 1/10W
R258 1-216-813-11 METAL CHIP 220 5% 1/10W
R260 1-216-813-11 METAL CHIP 220 5% 1/10W
R261 1-216-809-11 METAL CHIP 100 5% 1/10W
R262 1-216-797-11 METAL CHIP 10 5% 1/10W
R263 1-216-797-11 METAL CHIP 10 5% 1/10W
R264 1-216-809-11 METAL CHIP 100 5% 1/10W
R266 1-216-833-11 METAL CHIP 10K 5% 1/10W
R267 1-216-809-11 METAL CHIP 100 5% 1/10W
R268 1-216-833-11 METAL CHIP 10K 5% 1/10W
R269 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X200 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
************************************************************
KEY BOARD
**********
< CONNECTOR >
CN700 1-580-057-11 PIN, CONNECTOR (SMD) 4P
* CN701 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< RESISTOR >
R700 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R701 1-216-821-11 METAL CHIP 1K 5% 1/10W
R702 1-216-809-11 METAL CHIP 100 5% 1/10W
R703 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R704 1-216-821-11 METAL CHIP 1K 5% 1/10W
R705 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S700 1-786-650-21 SWITCH, TACTILE (VOLUME +)
S701 1-786-650-21 SWITCH, TACTILE (VOLUME –)
S702 1-786-650-21 SWITCH, TACTILE (
Z
)
S703 1-786-650-21 SWITCH, TACTILE (FUNCTION)
S704 1-786-650-21 SWITCH, TACTILE (
x
)
S705 1-786-650-21 SWITCH, TACTILE (
N
)
************************************************************
A-1746-703-A MAIN BOARD, COMPLETE
********************
< CAPACITOR >
* C501 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C502 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C503 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
* C504 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C505 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C506 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C507 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C508 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C509 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C511 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C515 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C516 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C518 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C519 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C521 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C522 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C524 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C525 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C526 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C527 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C528 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C529 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C532 1-104-656-11 ELECT 2200uF 20% 6.3V
C533 1-126-924-11 ELECT 330uF 20% 10V
C534 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C535 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C536 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C537 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C705 1-104-658-91 ELECT 100uF 20% 10V
C706 1-126-964-11 ELECT 10uF 20% 50V
C707 1-126-964-11 ELECT 10uF 20% 50V
C713 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C714 1-126-964-11 ELECT 10uF 20% 50V
C715 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C716 1-126-964-11 ELECT 10uF 20% 50V
C717 1-126-964-11 ELECT 10uF 20% 50V
C718 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C719 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C720 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C721 1-104-658-91 ELECT 100uF 20% 10V
C722 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C723 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C724 1-104-658-91 ELECT 100uF 20% 10V
C725 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C726 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C727 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C728 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C729 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C730 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C731 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C732 1-104-658-91 ELECT 100uF 20% 10V
C733 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C735 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C736 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C737 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C3000 1-126-933-11 ELECT 100uF 20% 16V
C3001 1-126-947-11 ELECT 47uF 20% 35V
C3002 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
C3003 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C3005 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3011 1-165-726-31 ELECT 56uF 20% 16V
C3012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3014 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
INCLUDE KEY MAIN
Note: When the MAIN board is replaced, spread the compound referring to “NOTE
OF REPLACING THE IC3100 AND IC3200 ON THE MAIN BOARD AND
THE COMPLETE MAIN BOARD” on servicing notes (page 8).
