Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
9999
F-USB BOARD
***********
< CONNECTOR >
CN100 1-822-423-11 CONNECTOR, USB (A) (
)
CN101 1-784-922-11 PIN, CONNECTOR 5P
************************************************************
INCLUDE BOARD
**************
< CAPACITOR >
C200 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C202 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C203 1-162-921-11 CERAMIC CHIP 33PF 5% 50V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C205 1-126-964-11 ELECT 10uF 20% 50V
C206 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C207 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C208 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C209 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C210 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C211 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C213 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C214 1-104-656-11 ELECT 2200uF 20% 6.3V
C215 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C216 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C217 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C218 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C222 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C223 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C224 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C225 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C226 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C227 1-104-655-91 ELECT 470uF 20% 6.3V
C228 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C229 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C230 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C231 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C232 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C233 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C234 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C235 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C236 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C237 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C238 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C239 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C242 1-126-964-11 ELECT 10uF 20% 50V
C243 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C244 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C245 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C247 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C248 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C249 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C250 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C251 1-137-649-31 ELECT 220uF 20% 10V
C252 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C253 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C254 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C258 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C259 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN200 1-820-115-51 CONNECTOR, FFC/FPC 15P
CN203 1-821-747-11 CONNECTOR, CARD EDGE 20P (L) (EZW-RT10)
CN204 1-779-977-11 PIN, CONNECTOR 6P
< DIODE >
D200 6-500-848-01 DIODE MC2840-T112-1
< IC >
IC200 8-759-591-61 IC TC7WHU04FU (TE12R)
IC201 6-702-302-01 IC TK11133CSCL-G
IC202 6-712-613-01 IC SI-3010KM-TLS
IC203 6-713-513-01 IC AK4127VF-E2
IC204 6-713-513-01 IC AK4127VF-E2
IC205 6-713-513-01 IC AK4127VF-E2
IC206 6-710-554-01 IC PCM1808PWR
IC207 8-759-546-74 IC TC7WH157FU (TE12R)
< COIL >
L200 1-481-524-11 INDUCTOR 10uH
L201 1-414-398-11 INDUCTOR 10uH
L202 1-481-524-11 INDUCTOR 10uH
L203 1-481-524-11 INDUCTOR 10uH
L204 1-481-524-11 INDUCTOR 10uH
L205 1-414-398-11 INDUCTOR 10uH
< RESISTOR >
R202 1-216-821-11 METAL CHIP 1K 5% 1/10W
R203 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R204 1-216-845-11 METAL CHIP 100K 5% 1/10W
R205 1-216-845-11 METAL CHIP 100K 5% 1/10W
R206 1-216-813-11 METAL CHIP 220 5% 1/10W
R207 1-216-821-11 METAL CHIP 1K 5% 1/10W
R209 1-216-809-11 METAL CHIP 100 5% 1/10W
R210 1-216-809-11 METAL CHIP 100 5% 1/10W
R211 1-216-809-11 METAL CHIP 100 5% 1/10W
R212 1-216-809-11 METAL CHIP 100 5% 1/10W
R213 1-216-809-11 METAL CHIP 100 5% 1/10W
R214 1-216-809-11 METAL CHIP 100 5% 1/10W
R215 1-216-809-11 METAL CHIP 100 5% 1/10W
R216 1-216-809-11 METAL CHIP 100 5% 1/10W
R217 1-216-809-11 METAL CHIP 100 5% 1/10W
R218 1-216-809-11 METAL CHIP 100 5% 1/10W
R219 1-216-809-11 METAL CHIP 100 5% 1/10W
R220 1-216-809-11 METAL CHIP 100 5% 1/10W
R221 1-216-809-11 METAL CHIP 100 5% 1/10W
R222 1-216-821-11 METAL CHIP 1K 5% 1/10W
R223 1-216-809-11 METAL CHIP 100 5% 1/10W
R225 1-216-809-11 METAL CHIP 100 5% 1/10W
R226 1-216-821-11 METAL CHIP 1K 5% 1/10W
R227 1-216-821-11 METAL CHIP 1K 5% 1/10W
R228 1-216-821-11 METAL CHIP 1K 5% 1/10W
R241 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R242 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R243 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R246 1-216-809-11 METAL CHIP 100 5% 1/10W
R247 1-216-809-11 METAL CHIP 100 5% 1/10W
R248 1-216-813-11 METAL CHIP 220 5% 1/10W
