Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
98
R47 1-216-841-11 METAL CHIP 47K 5% 1/10W
R48 1-216-837-11 METAL CHIP 22K 5% 1/10W
R49 1-216-837-11 METAL CHIP 22K 5% 1/10W
R50 1-216-841-11 METAL CHIP 47K 5% 1/10W
R51 1-216-841-11 METAL CHIP 47K 5% 1/10W
R52 1-216-864-11 SHORT CHIP 0
R53 1-216-821-11 METAL CHIP 1K 5% 1/10W
R54 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R55 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R56 1-216-864-11 SHORT CHIP 0
R57 1-216-864-11 SHORT CHIP 0
R58 1-216-845-11 METAL CHIP 100K 5% 1/10W
R60 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R61 1-216-821-11 METAL CHIP 1K 5% 1/10W
R62 1-216-845-11 METAL CHIP 100K 5% 1/10W
R65 1-216-864-11 SHORT CHIP 0
R71 1-216-833-11 METAL CHIP 10K 5% 1/10W
R72 1-216-833-11 METAL CHIP 10K 5% 1/10W
R73 1-216-833-11 METAL CHIP 10K 5% 1/10W
R74 1-216-821-11 METAL CHIP 1K 5% 1/10W
R75 1-216-821-11 METAL CHIP 1K 5% 1/10W
R76 1-216-821-11 METAL CHIP 1K 5% 1/10W
R77 1-216-864-11 SHORT CHIP 0
R85 1-216-834-11 METAL CHIP 12K 5% 1/10W
R86 1-216-835-11 METAL CHIP 15K 5% 1/10W
R87 1-216-821-11 METAL CHIP 1K 5% 1/10W
R88 1-216-864-11 SHORT CHIP 0
0 R89 1-215-865-51 METAL OXIDE 220 5% 1W F
R90 1-216-864-11 SHORT CHIP 0
R91 1-216-833-11 METAL CHIP 10K 5% 1/10W
R93 1-216-864-11 SHORT CHIP 0
R99 1-216-821-11 METAL CHIP 1K 5% 1/10W
< SWITCH >
S10 1-798-148-11 SWITCH, SLIDE (S-AIR ID)
************************************************************
A-1746-097-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C803 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-126-786-11 ELECT 47uF 20% 16V
C807 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C808 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C810 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C811 1-126-382-11 ELECT 100uF 20% 16V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C816 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C817 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C818 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C819 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C820 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C821 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C822 1-119-943-91 ELECT 47uF 20% 50V
C823 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C824 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C825 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C826 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C833 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C834 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C837 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
< CONNECTOR >
CN801 1-779-283-11 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D800 6-503-085-01 LED SLD430WBD2PT31XN (ILLUMINATION)
D803 6-500-848-01 DIODE MC2840-T112-1
D804 6-500-848-01 DIODE MC2840-T112-1
D805 6-501-729-01 DIODE MAZ8051GLLS0
D807 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC801 6-702-302-01 IC TK11133CSCL-G
IC802 6-713-497-01 IC HT16515
IC803 6-600-767-01 IC PNA4823M02S0
< COIL >
L801 1-410-671-31 INDUCTOR 47uH
L802 1-410-671-31 INDUCTOR 47uH
L803 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND800 1-483-114-11 INDICATOR TUBE, FLUORESCENT
< TRANSISTOR >
Q800 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q801 8-729-028-96 TRANSISTOR DTC114EUA-T106
Q802 6-550-363-01 TRANSISTOR 2SB1690KT146
Q803 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q804 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
< RESISTOR >
R803 1-216-817-11 METAL CHIP 470 5% 1/10W
R804 1-216-809-11 METAL CHIP 100 5% 1/10W
R805 1-216-817-11 METAL CHIP 470 5% 1/10W
R806 1-216-817-11 METAL CHIP 470 5% 1/10W
R807 1-216-841-11 METAL CHIP 47K 5% 1/10W
R809 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R812 1-216-821-11 METAL CHIP 1K 5% 1/10W
R813 1-216-839-11 METAL CHIP 33K 5% 1/10W
R814 1-216-805-11 METAL CHIP 47 5% 1/10W
R817 1-216-845-11 METAL CHIP 100K 5% 1/10W
R819 1-216-821-11 METAL CHIP 1K 5% 1/10W
R820 1-216-809-11 METAL CHIP 100 5% 1/10W
R821 1-216-809-11 METAL CHIP 100 5% 1/10W
R822 1-216-809-11 METAL CHIP 100 5% 1/10W
R823 1-216-844-11 METAL CHIP 82K 5% 1/10W
R825 1-216-805-11 METAL CHIP 47 5% 1/10W
R828 1-216-821-11 METAL CHIP 1K 5% 1/10W
< TRANSFORMER >
T800 1-445-686-11 D.C-D.C. CONVERTER TRANSFORMER
************************************************************
