Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
110
R1577 1-218-990-81 SHORT CHIP 0
R1578 1-218-990-81 SHORT CHIP 0
R1579 1-218-990-81 SHORT CHIP 0
R1580 1-218-990-81 SHORT CHIP 0
R1581 1-218-990-81 SHORT CHIP 0
R1582 1-218-990-81 SHORT CHIP 0
R1584 1-218-990-81 SHORT CHIP 0
R1585 1-218-990-81 SHORT CHIP 0
R1586 1-218-941-81 METAL CHIP 100 5% 1/16W
R1598 1-218-990-81 SHORT CHIP 0
R1609 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1611 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1612 1-218-977-11 METAL CHIP 100K 5% 1/16W
R1613 1-218-977-11 METAL CHIP 100K 5% 1/16W
R2307 1-218-973-11 METAL CHIP 47K 5% 1/16W
R2308 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2309 1-218-969-11 METAL CHIP 22K 5% 1/16W
R2411 1-218-971-11 METAL CHIP 33K 5% 1/16W
R2412 1-218-971-11 METAL CHIP 33K 5% 1/16W
R2416 1-208-720-11 METAL CHIP 36K 0.5% 1/16W
R2417 1-208-720-11 METAL CHIP 36K 0.5% 1/16W
R2418 1-218-965-11 METAL CHIP 10K 5% 1/16W
R2419 1-218-990-81 SHORT CHIP 0
R2420 1-220-203-11 METAL CHIP 51K 5% 1/16W
R2421 1-220-206-11 METAL CHIP 91K 5% 1/16W
R2422 1-220-206-11 METAL CHIP 91K 5% 1/16W
R2442 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R2444 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R2446 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R2447 1-248-476-11 RES-CHIP 0.16 1% 1/3W
R2483 1-218-990-81 SHORT CHIP 0
R2487 1-218-990-81 SHORT CHIP 0
R2492 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R2494 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R2496 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB101 1-234-372-11 RES, NETWORK 100 (1005X4)
RB102 1-234-372-11 RES, NETWORK 100 (1005X4)
RB103 1-234-372-11 RES, NETWORK 100 (1005X4)
RB104 1-234-372-11 RES, NETWORK 100 (1005X4)
RB105 1-234-372-11 RES, NETWORK 100 (1005X4)
RB106 1-234-372-11 RES, NETWORK 100 (1005X4)
RB201 1-234-372-11 RES, NETWORK 100 (1005X4)
RB202 1-234-372-11 RES, NETWORK 100 (1005X4)
RB203 1-234-372-11 RES, NETWORK 100 (1005X4)
RB204 1-234-372-11 RES, NETWORK 100 (1005X4)
RB205 1-234-372-11 RES, NETWORK 100 (1005X4)
RB206 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1101 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1102 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1103 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1201 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1503 1-234-372-11 RES, NETWORK 100 (1005X4)
< THERMISTOR >
TH1501 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X401 1-814-278-11 VIBRATOR, CRYSTAL (27MHz)
X802 1-814-242-11 VIBRATOR, CRYSTAL (25MHz)
X1201 1-814-242-11 VIBRATOR, CRYSTAL (25MHz)
************************************************************
P-KEY BOARD
***********
< CAPACITOR >
C750 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
* CN750 1-580-055-21 PIN, CONNECTOR (SMD) 2P
< RESISTOR >
R750 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S750 1-786-650-21 SWITCH, TACTILE (I/
1
)
************************************************************
A-1745-455-A POWER BOARD, COMPLETE
***********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C901 1-114-594-21 FILM 0.22uF 10% 310V
0 C902 1-116-397-21 FILM 0.33uF 10% 310V
0 C903 1-112-330-11 ELECT (BLOCK) 1000uF 20% 200V
0 C905 1-116-392-11 FILM 0.01uF 5% 400V
0 C907 1-162-965-91 CERAMIC CHIP 0.0015uF 10% 50V
0 C908 1-107-909-91 ELECT 47uF 20% 50V
0 C909 1-162-960-91 CERAMIC CHIP 220PF 10% 50V
0 C910 1-126-965-91 ELECT 22uF 20% 50V
0 C916 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
0 C918 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C920 1-112-887-51 CERAMIC 0.01uF 20% 250V
0 C921 1-117-220-81 CERAMIC 150PF 5% 2KV
0 C922 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
0 C923 1-164-390-91 CERAMIC CHIP 330PF 5% 50V
0 C924 1-116-393-11 FILM 0.0033uF 5% 400V
0 C925 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C926 1-107-930-91 ELECT 22uF 20% 100V
C927 1-112-223-11 ELECT 3300uF 20% 10V
C928 1-112-232-11 ELECT 2700uF 20% 16V
C929 1-112-241-21 ELECT 1000uF 20% 25V
C932 1-114-994-11 ELECT 2200uF 20% 35V
C933 1-114-994-11 ELECT 2200uF 20% 35V
C934 1-112-831-31 ELECT 2200uF 20% 35V
C935 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C936 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C937 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
0 C938 1-112-869-51 CERAMIC 470PF 10% 250V
C939 1-136-165-00 FILM 0.1uF 5% 50V
C940 1-112-228-21 ELECT 1000uF 20% 16V
C942 1-126-941-11 ELECT 470uF 20% 25V
C943 1-126-935-11 ELECT 470uF 20% 16V
C950 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
MB-134 P-KEY POWER
Note: When the POWER board is replaced, spread the compound referring to “NOTE OF
REPLACING THE D913, D931, IC901 AND IC921 ON THE POWER BOARD
AND THE COMPLETE POWER BOARD” on servicing notes (page 9).
