Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
111111
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C963 1-112-870-51 CERAMIC 0.001uF 20% 250V
0 C964 1-112-870-51 CERAMIC 0.001uF 20% 250V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C972 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C973 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C975 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
0 C980 1-117-828-11 FILM 3300PF 3% 1.5KV
0 C981 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
C983 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C984 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C987 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C990 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C991 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C992 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C993 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C997 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
0 C998 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
0 CN901 1-564-321-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CN904 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
< DIODE >
0 D901 8-719-082-57 DIODE D5SBA60F01
0 D902 8-719-063-74 DIODE D1NL20U-TR2
0 D906 6-501-817-01 DIODE MA2J1110GLS0
0 D907 6-501-817-01 DIODE MA2J1110GLS0
0 D908 6-501-817-01 DIODE MA2J1110GLS0
0 D909 6-501-817-01 DIODE MA2J1110GLS0
0 D910 6-501-817-01 DIODE MA2J1110GLS0
0 D913 6-500-241-01 DIODE SARS03
0 D914 6-501-817-01 DIODE MA2J1110GLS0
D931 6-501-849-01 DIODE FMX-22SL
D942 6-502-518-01 DIODE 50PQSA065-FA9
D943 8-719-080-53 DIODE RK36LF-B3
0 D946 6-502-234-01 DIODE EG01C LF-F7
D954 6-500-288-11 DIODE EK19LF-F7
D955 6-500-288-11 DIODE EK19LF-F7
0 DZ901 6-501-782-01 DIODE MAZ8180GMLS0
0 DZ902 6-502-231-01 DIODE MAZ8220GLLSO
0 DZ903 6-501-787-01 DIODE MAZ8220GMLS0
0 DZ905 8-719-083-71 DIODE UDZSUSTE-1730B
0 DZ915 6-501-760-01 DIODE MAZ8100GMLS0
0 DZ951 8-719-083-71 DIODE UDZSUSTE-1730B
< FUSE HOLDER >
FH901 1-533-217-31 FUSE HOLDER
FH902 1-533-217-31 FUSE HOLDER
< FUSIBLE >
0 FR929 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
0 IC901 6-707-741-01 IC STR-F6138-LF1352
0 IC921 6-714-671-01 IC STR-Y6763
IC923 6-71
1-947-01 IC MM1431CURE
IC932 6-711-947-01 IC MM1431CURE
IC941 6-712-613-01 IC SI-3010KM-TLS
< COIL >
L931
1-457-878-65
INDUCT
OR
2.2uH
L954
1-457-578-1
1
INDUCT
OR 10uH
L956 1-457-578-11 INDUCTOR 10uH
L963 1-457-725-11 INDUCTOR 4.7uH
L964 1-457-725-11 INDUCTOR 4.7uH
L967 1-469-525-91 INDUCTOR 10uH
< LINE FILTER >
0 LF901 1-457-449-11 COIL, LINE FILTER
0 LF902 1-457-449-11 COIL, LINE FILTER
< PHOTO COUPLER >
0 PC901 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC902 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC903 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
0 Q901 8-729-231-15 TRANSISTOR 2SA1015TP-YGR
0 Q922 6-550-702-01 TRANSISTOR 2SC3243-TP-E
Q943 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q949 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q950 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q969 6-551-699-01 TRANSISTOR ISA1602AM1TP-1EF
< RESISTOR >
0 R901 1-219-759-51 METAL 1M 5% 1/2W F
0 R903 1-250-299-65 METAL OXIDE 33K 5% 3W F
0 R904 1-250-299-65 METAL OXIDE 33K 5% 3W F
0 R905 1-216-797-91 METAL CHIP 10 5% 1/10W
0 R906 1-216-827-91 METAL CHIP 3.3K 5% 1/10W
0 R907 1-216-833-91 METAL CHIP 10K 5% 1/10W
0 R908 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R909 1-216-833-91 METAL CHIP 10K 5% 1/10W
0 R910 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
0 R911 1-216-813-91 METAL CHIP 220 5% 1/10W
0 R914 1-248-180-11 METAL 0.034 5% 5W F
0 R916 1-250-297-65 METAL OXIDE 100K 5% 3W F
0 R917 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R919 1-216-837-91 METAL CHIP 22K 5% 1/10W
0 R922 1-250-262-41 METAL 0.39 5% 2W F
0 R923 1-218-879-91 METAL CHIP 22K 0.5% 1/10W
0 R925 1-216-797-91 METAL CHIP 10 5% 1/10W
0 R926 1-218-847-91 METAL CHIP 1K 0.5% 1/10W
R931 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R932 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R933 1-216-821-11 METAL CHIP 1K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R938 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R939 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R940 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
POWER
Note 1: When D913 and D931 on the POWER board are replaced,
spread the compound referring to “NOTE OF REPLACING
THE D913, D931, IC901 AND IC921 ON THE POWER
BOARD AND THE COMPLETE POWER BOARD” on ser-
vicing notes (page 9).
Note 2: When IC901 and IC921 on the POWER board are replaced,
spread the compound referring to “NOTE OF REPLACING
THE D913, D931, IC901 AND IC921 ON THE POWER
BOARD AND THE COMPLETE POWER BOARD” on ser-
vicing notes (page 9).
