Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E770W
112
R941 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R942 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R945 1-216-837-11 METAL CHIP 22K 5% 1/10W
R946 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R949 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R951 1-218-875-91 METAL CHIP 15K 0.5% 1/10W
R954 1-218-861-11 METAL CHIP 3.9K 0.5% 1/10W
R955 1-216-821-11 METAL CHIP 1K 5% 1/10W
R956 1-216-817-11 METAL CHIP 470 5% 1/10W
R959 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R963 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R965 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R966 1-216-821-11 METAL CHIP 1K 5% 1/10W
R967 1-216-821-11 METAL CHIP 1K 5% 1/10W
R972 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R976 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R978 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
R979 1-216-841-11 METAL CHIP 47K 5% 1/10W
0 R992 1-216-793-91 METAL CHIP 4.7 5% 1/10W
R998 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R999 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
< TRANSFORMER >
0 T901 1-443-649-11 TRANSFORMER, CONVERTER
0 T903 1-445-320-11 TRANSFORMER, CONVERTER
< THERMISTOR >
0 TH901 1-805-841-21 THERMISTOR, NTC 3.0
< VARISTOR >
0 VDR901 1-802-839-11 VARISTOR
************************************************************
REG BOARD
*********
< CAPACITOR >
C400 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C401 1-126-934-11 ELECT 220uF 20% 16V
C403 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C404 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C405 1-126-941-11 ELECT 470uF 20% 25V
C408 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C409 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C411 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
C412 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C414 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C415 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C426 1-104-666-11 ELECT 220uF 20% 25V
C428 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C431 1-126-949-11 ELECT 220uF 20% 35V
< CONNECTOR >
* CN400 1-691-774-11 PLUG (MICRO CONNECTOR) 12P
CN403 1-784-926-11 PIN, CONNECTOR 11P
< DIODE >
D402 8-719-083-63 DIODE UDZSUSTE-1713B
D403 8-719-083-66 DIODE UDZSUSTE-1718B
D405 8-719-083-87 DIODE UDZSUSTE-1733B
D406 6-500-288-11 DIODE EK19LF-F7
D407 6-500-288-11 DIODE EK19LF-F7
< IC >
IC400 6-702-302-01 IC TK11133CSCL-G
IC402 6-715-070-01 IC TK72270CSCL-GH
< COIL >
L401
1-457-725-11 INDUCTOR 4.7uH
<
TRANSISTOR >
Q401 8-729-028-96 FET DTC114EUA-T106
Q402 6-551-460-01 TRANSISTOR RSR025P03TL
< RESISTOR >
R402 1-216-295-91 SHORT CHIP 0
R404 1-216-295-91 SHORT CHIP 0
R406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R411 1-216-821-11 METAL CHIP 1K 5% 1/10W
R415 1-216-841-11 METAL CHIP 47K 5% 1/10W
R417 1-216-839-11 METAL CHIP 33K 5% 1/10W
R420 1-216-843-11 METAL CHIP 68K 5% 1/10W
R421 1-216-821-11 METAL CHIP 1K 5% 1/10W
R422 1-216-841-11 METAL CHIP 47K 5% 1/10W
R423 1-216-841-11 METAL CHIP 47K 5% 1/10W
************************************************************
R-USB BOARD
***********
< CONNECTOR >
CN150 1-842-128-11 USB CONNECTOR (
)
CN151 1-784-922-11 PIN, CONNECTOR 5P
*************************************************************
MISCELLANEOUS
**************
53 1-966-988-11 HARNESS (USB)
56 1-966-989-12 HARNESS (USB)
0 57 1-837-308-11 CORD, POWER-SUPPLY
102 1-828-954-51 WIRE (FLAT TYPE) (9 CORE)
154 1-828-343-51 WIRE (FLAT TYPE) (15 CORE)
155 1-828-400-51 WIRE (FLAT TYPE) (27 CORE)
157 1-828-346-51 WIRE (FLAT TYPE) (17 CORE)
158 1-828-740-51 WIRE (FLAT TYPE) (18 CORE)
159 1-828-730-51 WIRE (FLAT TYPE) (16 CORE)
160 1-828-341-51 WIRE (FLAT TYPE) (15 CORE)
202 A-1750-926-A LOADING FOR SERVICE
0 206 8-820-430-02 DEVICE, OPTICAL (KEM-460AAA/C2RP)
207 1-837-660-51 WIRE (FLAT TYPE) (9 CORE)
208 1-837-658-51 WIRE (FLAT TYPE) (45 CORE)
209 1-837-659-51 WIRE (FLAT TYPE) (5 CORE)
0 F901 1-533-311-12 FUSE, GLASS (DIA.5) (8A/125V)
M3001 1-787-931-11 DC FAN
TU1 1-693-781-11 TUNER (FM)
