Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
70
C3081 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3082 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3083 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3084 1-114-885-51 FILM 1uF 5% 50V
C3085 1-114-885-51 FILM 1uF 5% 50V
C3086 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
C3087 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
C3088 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3089 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3091 1-112-246-11 ELECT 100uF 20% 35V
C3092 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3093 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
C3094 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
C3095 1-126-952-11 ELECT 1000uF 20% 35V
C3096 1-126-947-11 ELECT 47uF 20% 35V
C3097 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3098 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C3099 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3100 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3102 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3105 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3106 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3107 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3108 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3109 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3110 1-112-246-11 ELECT 100uF 20% 35V
C3111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3112 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3113 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3114 1-114-885-51 FILM 1uF 5% 50V
C3115 1-114-885-51 FILM 1uF 5% 50V
C3116 1-112-246-11 ELECT 100uF 20% 35V
C3117 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3119 1-126-952-11 ELECT 1000uF 20% 35V
C3120 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3121 1-114-869-11 CERAMIC CHIP 2.2uF 10% 6.3V
C3123 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3124 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3125 1-112-246-11 ELECT 100uF 20% 35V
C3126 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3127 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3128 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3129 1-114-885-51 FILM 1uF 5% 50V
C3130 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3131 1-114-885-51 FILM 1uF 5% 50V
C3132 1-126-947-11 ELECT 47uF 20% 35V
C3133 1-112-246-11 ELECT 100uF 20% 35V
C3134 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3135 1-126-952-11 ELECT 1000uF 20% 35V
C3137 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3138 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3139 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3140 1-126-934-11 ELECT 220uF 20% 16V
C3141 1-100-436-91 CERAMIC CHIP 0.033uF 10% 25V
C3142 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3143 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3144 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3145 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C3146 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C3148 1-126-933-11 ELECT 100uF 20% 16V
C3149 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3150 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C3151 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3152 1-126-923-91 ELECT 220uF 20% 10V
C3154 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C3155 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C9973 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN400 1-784-770-11 CONNECTOR, FFC 9P
CN402 1-820-116-41 CONNECTOR, FFC/FPC 17P (TZ230/TZ630)
CN506 1-820-113-41 CONNECTOR, FFC/FPC 11P
CN508 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
CN1101 1-815-763-32 CONNECTOR, FFC/FPC 24P
CN1105 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN1501 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN1502 1-779-273-11 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
CN1701 (Not supplied) CONNECTOR, HDMI 19P (HDMI OUT)
CN2101 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D400 6-500-848-01 DIODE MC2840-T112-1 (TZ210/TZ510/TZ710)
D502 6-501-817-01 DIODE MA2J1110GLS0
D503 6-501-817-01 DIODE MA2J1110GLS0
D2101 6-501-749-01 DIODE MAZ8082G0LS0
D2102 6-501-592-01 DIODE EDZCTE616.8B
D2103 6-501-592-01 DIODE EDZCTE616.8B
D4002 6-501-817-01 DIODE MA2J1110GLS0
D4004 6-501-817-01 DIODE MA2J1110GLS0
D9712 6-501-817-01 DIODE MA2J1110GLS0
< FERRITE BEAD >
FB471 1-500-283-11 INDUCTOR, FERRITE BEAD
*
FB1106 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB1107 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB1108 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB1109 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB1111 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB1112 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB1113 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB1115 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB1116 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB1117 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB1118 1-400-974-21 INDUCTOR (EMI FERRITE)
*
FB2101 1-400-973-21 INDUCTOR (EMI FERRITE)
*
FB2103 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2104 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2105 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2125 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2126 1-500-283-11 INDUCTOR, FERRITE BEAD
MAIN
Ver. 1.1
To Next Page
