Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
7171
< IC >
IC307 8-759-680-48 IC TC7WH157FK(TE85R)
IC400 6-703-622-01 IC MM1508XNRE (TZ210/TZ510/TZ710)
IC401 8-759-430-37 IC MC14052BDTR2
IC403 6-712-744-01 IC TK11190CSCL-G
IC404 6-710-554-01 IC PCM1808PWR
IC471 6-707-853-01 IC TC74LCX541FT(EKJ)
IC503 A-1748-165-A IC R5F364AEDFA (for SERVICE)
IC504 6-705-338-01 IC TK11250CMCL-G
IC506 6-705-203-01 IC S-80935CNMC-G85T2G
IC507 (Not supplied) IC MM1665AHBE
IC509 6-712-613-01 IC SI-3010KM-TLS
IC510 6-709-584-01 IC MM1663DHBE
IC1101 6-714-722-01 IC CXD9927R-B (CND,UK)
IC1101 6-714-723-01 IC CXD9917R-B (EXCEPT CND,UK)
IC1102 6-715-433-01 IC MX29LV320DBTI-70-OHI-1002UC
(CND,E32,AR,MX)
IC1102 6-715-434-01 IC MX29LV320DBTI-70-OHI-1002CE
(E3,E12,AUS,EA,RU,SAF,AEP,UK)
IC1102 6-715-435-01 IC MX29LV320DBTI-70-OHI-1002GA
(HK,PH,SP,TH,TW,CH)
IC1103 (Not supplied) IC BR24S64F-WE2
IC1104 6-713-754-01 IC W9864G6IH-6J-ER10
IC1105 6-702-302-01 IC TK11133CSCL-G
IC1107 6-702-302-01 IC TK11133CSCL-G
IC1110 6-707-739-01 IC MM1661JTRE
IC1501 (Not supplied) IC BD8203EFV-E2
IC1705 8-759-592-47 IC TC7SZ08FU(TE85R)
IC1707 6-705-337-01 IC TK11150CSCL-G
IC1708 6-702-302-01 IC TK11133CSCL-G
IC2200 6-713-555-01 IC MFI341S2161
(TZ210:AUS/TZ230:UK/TZ510:CND)
IC3000 6-713-634-01 IC CXD9965TN
IC3001 6-705-979-01 IC CXD9788AR
IC3002 6-713-634-01 IC CXD9965TN
IC3003 6-705-979-01 IC CXD9788AR
IC3004 6-713-634-01 IC CXD9965TN
IC3005 6-705-979-01 IC CXD9788AR
IC3006 6-714-743-01 IC MM3404A18URE
IC3007 6-706-492-01 IC TC7SHU04FU(T5RSOJF)
< JACK >
J400 1-822-338-11 JACK, PIN 3P (VIDEO OUT,
TV/CABLE (AUDIO IN L/R))
(TZ210:CND/TZ510:CND)
J400 1-822-338-11 JACK, PIN 3P (VIDEO OUT,TV (AUDIO IN L/R))
(TZ210:EXCEPT CND/TZ510:EXCEPT CND/TZ710)
< COIL >
L400 1-469-525-91 INDUCTOR 10uH
L401 1-469-525-91 INDUCTOR 10uH (TZ210/TZ510/TZ710)
L402 1-469-525-91 INDUCTOR 10uH
L403 1-469-525-91 INDUCTOR 10uH
L471 1-469-527-91 INDUCTOR 47uH
L1701 1-457-374-21 COIL, COMMON MODE CHOKE
L1702 1-457-374-21 COIL, COMMON MODE CHOKE
L1703 1-457-374-21 COIL, COMMON MODE CHOKE
L1704 1-457-374-21 COIL, COMMON MODE CHOKE
L2101 1-457-374-21 COIL, COMMON MODE CHOKE
L3000 1-457-579-11 COIL, CHOKE 10uH
L3001 1-457-579-11 COIL, CHOKE 10uH
L3002 1-457-077-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3003 1-457-078-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3004 1-457-077-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3005 1-457-078-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3006 1-457-579-11 COIL, CHOKE 10uH
L3007 1-457-077-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3008 1-457-078-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3009 1-457-077-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3010 1-457-078-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3011 1-457-579-11 COIL, CHOKE 10uH
L3012 1-457-078-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3013 1-457-077-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3014 1-457-078-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3015 1-457-077-11 COIL, AIR-CORE
(CND,AUS,EA,HK,RU,SAF,AEP,UK,TW,CH)
L3016 1-457-579-11 COIL, CHOKE 10uH
L3017 1-457-579-11 COIL, CHOKE 10uH
L3018 1-469-525-91 INDUCTOR 10uH
L3019 1-469-525-91 INDUCTOR 10uH
L3020 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q400 8-729-029-06 TRANSISTOR DTC124EUA-T106
Q501 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q1101 6-552-279-01 FET RT3K66M-T111-1
Q1102 6-550-653-01 TRANSISTOR QST8TR
Q1103 8-729-029-06 TRANSISTOR DTC124EUA-T106
Q1701 6-552-279-01 FET RT3K66M-T111-1
Q2101 6-551-272-01 TRANSISTOR RT3CLLM
Q3003 6-551-272-01 TRANSISTOR RT3CLLM
Q3004 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q3005 6-551-271-01 TRANSISTOR RT3AMMM
Q3007 6-551-271-01 TRANSISTOR RT3AMMM
Q3009 6-551-271-01 TRANSISTOR RT3AMMM
Q3011 6-551-271-01 TRANSISTOR RT3AMMM
Q3013 6-551-271-01 TRANSISTOR RT3AMMM
Q3015 6-551-271-01 TRANSISTOR RT3AMMM
Q9730 6-551-714-01 FET INK0001AC1-T112A-1
< RESISTOR >
R316 1-216-801-11 METAL CHIP 22 5% 1/10W
R317 1-216-801-11 METAL CHIP 22 5% 1/10W
R318 1-216-801-11 METAL CHIP 22 5% 1/10W
R319 1-216-801-11 METAL CHIP 22 5% 1/10W
R400 1-216-809-11 METAL CHIP 100 5% 1/10W
(TZ230/TZ630)
R401 1-216-809-11 METAL CHIP 100 5% 1/10W
(TZ230/TZ630)
R402 1-216-809-11 METAL CHIP 100 5% 1/10W
(TZ230/TZ630)
R403 1-216-864-11 SHORT CHIP 0
R404 1-216-864-11 SHORT CHIP 0
MAIN
Note:
When IC507, IC1103 and IC1501on the Main board is damaged, exchange
the new Main board for the Main board which IC damaged.
Ver. 1.1
To Next Page
